Electric Heat Wiring Diagram Cross Reference
The following table provides a cross-reference for diagrams for specic electric heat models.
TABLE 4
Electric Heat Section Model Wiring Diagram #
ECB38-4-5-6-4CB-5CB-6CB-P 537951-01
ECB38-8-9-8CB-9CB-P 537955-01
ECB38-12.5CB-15CB-P 537960-01
ECB38-20CB-P 537962-01
ECB38-25CB-P 537963-01
ECB38-8-10-15CB-Y 537964-01
ECB38-20CB25CB-Y 537957-01
