Code Description Code Description Code Description Code Unit Min Factory Max Comments
2-Sp Wat.2 3322 °C 5 / -10 7 17
*[Water SP] Outlet chilled water temperature
set point (see page 11 – IOM Climatic 50) –
minimum with Glycol according to %
3-Sp Out.1 3323 °C -10 22 50
*[Water SP] Ambiant air temperature set
point (see page 13 – IOM Climatic 50)
4-Sp Out.2 3324 °C -10 30 50
*[Water SP] Ambiant air temperature set
point (see page 13 – IOM Climatic 50)
5-Reactiv. 3325 %/°C 1 5 50
*[Capacity Factor] Reactivity factor for
cooling mode
6-Control 3326 °C 1 5 20
*[Capacity Factor] Control factor for
cooling mode
3-Water Heat 3330 1-Sp Wat.1 3331 °C 17 40 50
*[Water SP] Outlet hot water temperature set
point (see page 13 – IOM Climatic 50)
2-Sp Wat.2 3332 °C 17 40 50
*[Water SP] Outlet hot water temperature set
point (see page 13 – IOM Climatic 50)
3-Sp Out.1 3333 °C -10 19 50
*[Water SP] Ambiant air temperature set
point (see page 13 – IOM Climatic 50)
4-Sp Out.2 3334 °C -10 0 50
*[Water SP] Ambiant air temperature set
point (see page 13 – IOM Climatic 50)
5-Reactiv. 3335 %/°C 1 5 50
*[Capacity Factor] Reactivity factor for
heating mode
6-Control 3336 °C 1 5 20
*[Capacity Factor] Control factor for
heating mode
4-Safety 3340 1-Wat. Low 3341 °C 3 / -10 5 / -10 12
*[Safety limit] Chilled water outlet
temperature limit – minimum with Glycol
according to %
2-Wat. high 3342 °C 22 53 53
*[Safety limit] Hot water outlet temperature
limit
4-
Compressor
3400 1-Circuit 3410 1-Enable 3411
Liste : C1_ _ _ / C _2_ _ /
C12_ _ / C _ _3_ / C1_3_
/ C _23_ / C123_ / C _ _
_4 / C1_ _ 4 / C_2_4 /
C12 _4 / C _ _34 / C1_34
/ C_234 / C1234
1 3 / 15 3 / 15
*[Circ enable] Circuit operation management
– Circuit authorize to operate
2-Rotat. 3412
Liste : Auto. / C.1 / C.2 /
C.3 / C.4
0 0 4
*[Comp priority] Circuit priority management
2-Safety 3420 1-Frost 3421 °C -1/-20 -1 / -20 5
*[Safety limit] Freezing safety limit –
minimum with Glycol according to %
2-Time limit 3422 s 1 30 360
*[Safety limit] Lennox setting
3- T.Disch 3423 °C 90 110 120
*[Temp. SP] Discharge temperature set point
WAH only
4- W/Cd Mini 3424 °C 5 25 33
*[Safety limit] Condensing water outlet
temperature limit
5- W/Cd Maxi 3425 °C 20 55 66
*[Safety limit] Condensing water outlet
temperature limit
3-Defrost 3430 1-Mode 3431 Liste : Dynamic / Cyclic 0 0 2
*[ Function Defrost ] Choice of defrost: 1
= "cycling" or 0 ="dynamic"
