74
CLIMATIC 50, user manual – Chillers ranges CL50-CHILLERS/IOM
/
0906-E
74
Main
screen
Code Description Code Description Code Description Code Unit Min Factory Max Comments
2-Outside 3432 °C 8 10 20
*[ Function Defrost ] Authorization of
defrost - Threshold of outside
temperature (in °c)
3-Coil 3433 °C 1/-10 2 3 / 10
*[ Function Defrost ] Authorization of
defrost - Threshold of coil temperature (in
°c)
4-Time Limit 3434 mn 1 30 360
*[ Function Defrost ] Time limit for icing (in
minute) -For the dynamic defrost the unit
will run this minimum amount of time. If
cycling defrost this is the time delay to
start the defrost once the temperature
conditions are met.
5-Time Fc 3435 s 5 60 300
*[ Function Defrost ] Running time of fans
after defrost cycle in order to dry the
outside coil.
5-EEV 3500 1-Circuit 1 3510 1-SuperHeat 3511 °C 5 / 7 5 / 7 15
*[ EEV] Superheat set point – With Glycol
2-Anticipation 3512 % 0 80 100
*[ EEV] Lennox set point – EEV opening at
1st stage start
3-P 3513 °C 5 Calc 30
*[ EEV] Lennox set point – Proportional factor
4-I 3514 s 10 35 100
*[ EEV] Lennox set point – Integral factor
5-D 3515 s 0,5 1 3
*[ EEV] Lennox set point – Derivate factor
2-Circuit 2 3520 1-SuperHeat 3521 °C 5 / 7 5 / 7 15
*[ EEV] Superheat set point – With Glycol
2-Anticipation 3522 % 0 80 100
*[ EEV] Lennox set point – EEV opening at
1st stage start
3-P 3523 °C 5 Calc 30
*[ EEV] Lennox set point – Proportional factor
4-I 3524 s 10 35 100
*[ EEV] Lennox set point – Integral factor
5-D 3525 s 0,5 1 3
*[ EEV] Lennox set point – Derivate factor
3-Circuit 3 3530 1-SuperHeat 3531 °C 5 / 7 5 / 7 15
*[ EEV] Superheat set point – With Glycol
2-Anticipation 3532 % 0 80 100
*[ EEV] Lennox set point – EEV opening at
1st stage start
3-P 3533 °C 5 Calc 30
*[ EEV] Lennox set point – Proportional factor
4-I 3534 s 10 35 100
*[ EEV] Lennox set point – Integral factor
5-D 3535 s 0,5 1 3
*[ EEV] Lennox set point – Derivate factor
4-Circuit 4 3540 1-SuperHeat 3541 °C 5 / 7 5 / 7 15
*[ EEV] Superheat set point – With Glycol
2-Anticipation 3542 % 0 80 100
*[ EEV] Lennox set point – EEV opening at
1st stage start
3-P 3543 °C 5 Calc 30
*[ EEV] Lennox set point – Proportional factor
4-I 3544 s 10 35 100
*[ EEV] Lennox set point – Integral factor
5-D 3545 s 0,5 1 3
*[ EEV] Lennox set point – Derivate factor
