0906-E
75
Main
screen
Code Description Code Description Code Description Code Unit Min Factory Max Comments
6-
Ventilation
3600 1-Sp Cond. 3611 b 11 16 / 11 21
*[ HP SP] High pressure set point – for
R134a unit
2- C1 Reactiv. 3612 %/°C 1 10 50
*[ HP Factor] Reactivity set point for fan
operation
3- C2 Reactiv. 3613 %/°C 1 10 50
*[ HP Factor] Reactivity set point for fan
operation
4- C3 Reactiv. 3614 %/°C 1 10 50
*[ HP Factor] Reactivity set point for fan
operation
5- C4 Reactiv. 3615 %/°C 1 10 50
*[ HP Factor] Reactivity set point for fan
operation
6- DIS.COMP. 3616 bar 20 29
26,5
OR 22
*[ UNLOADING] Compressor set point for
unloading
7-Option 3700
8-Config. 3800 1-Unit 3810 1-Range 3811 Liste 0 ~ 8 / 6
*[ Configuration ] Unit model
2-Size 3812 Liste 0 ~ 83/126
*[ Configuration ] Type of unit
3- gaz 3813
Liste : R407c / R22 /
R134a
0 ~ 2
*[ Configuration ] Type of refrigerant
2-
Compressor
3820 1-EEV 3821 Yes/No ~ ~ ~
*[ Configuration ] Electronic expansion valve
2-LAK 3822 Yes/No ~ ~ ~
*[ Configuration ] All season control
3-Stages +. 3823 Yes/No ~ ~ ~
*[ Configuration ] For units with reciprocating
compressor extra capacity reduction
4-Starter 3824 Yes/No ~ ~ ~
*[ Configuration ] For units with compressor
soft starter
3-Ventilation 3830 1-Circuit 1 3831
Liste : No / Stages /
Modulation / Low Speed
0 0 3
*[ Configuration ] Fan configuration
No = No fans
Stages + = Single speed stage fans
Modulation = 1 fan with speed control, others
with single speed
Low Speed = 1 fan with 2 speed others with
single speed
2-Circuit 2 3832
Liste : No / Stages /
Modulation / Low Speed
0 0 3
*[ Configuration ] Fan configuration
No = No fans
Stages + = Single speed stage fans
Modulation = 1 fan with speed control, others
with single speed
Low Speed = 1 fan with 2 speed others with
single speed
3-Circuit 3 3833
Liste : No / Stages /
Modulation / Low Speed
0 0 3
*[ Configuration ] Fan configuration
No = No fans
Stages + = Single speed stage fans
Modulation = 1 fan with speed control, others
