76
CLIMATIC 50, user manual – Chillers ranges CL50-CHILLERS/IOM
/
0906-E
76
with single speed
Low Speed = 1 fan with 2 speed others with
single speed
Main
screen
Code Description Code Description Code Description Code Unit Min Factory Max Comments
4-Circuit 4 3834
Liste : No / Stages /
Modulation / Low Speed
0 0 3
*[ Configuration ] Fan configuration
No = No fans
Stages + = Single speed stage fans
Modulation = 1 fan with speed control, others
with single speed
Low Speed = 1 fan with 2 speed others with
single speed
4-Option. 3840 1-Pump 3841
Liste : No / Simple /
Double
0 ~ 2
*[ Configuration ] Pump configuration
2-Glycol 3842 % 0 ~ 50
*[ Configuration ] Glycol percentage
3-Free cooling 3843 Yes/No ~ ~ ~
*[ Configuration ] Free cooling option
4-Recovery 3844 Yes/No ~ ~ ~
*[ Configuration ] Heat recovery option
5-Out.
Custom.
3850 1-BE50.1 3851 0 0 20
*[Configuration] Free output to be
customised (First output of the extension
board BE50)
2-BE50.2 3852 0 0 20
*[Configuration] Free output to be
customised (Second output of the
extension board BE50)
3-BE50.3 3853 0 0 20
*[Configuration] Free output to be
customised (Third output of the extension
board BE50)
4-BE50.4 3854
Liste : Not Used / C.1
Alarm / C.2 Alarm / C.3
Alarm : C.4 Alarm / Fans
Al. / Pump Al. / Flow Al./
Heat. Mode / C.1 100% /
C.2 100% / C.3 100% /
C.4 100% / U. 100% / U.
On / Z:A / Z:B / Z:C / Uno /
Bms / Free
0 0 20
*[Configuration] Free output to be
customised (Fourth output of the
extension board BE50)
6-In. Custom. 3860 1-BE50.1 3861 0 0 9
*[Configuration] Free input to be
customised (input of the extension board
BE50)
2-BE50.2 3862 0 0 9
*[Configuration] Free input to be
customised (input of the extension board
BE50)
3-BE50.3 3863 0 0 9
*[Configuration] Free input to be
customised (input of the extension board
BE50)
4-BE50.4 3864
Liste : Not Used / Sw
Setpoint / Sw Cool. / Sw
Heat. / C1 Disable / C2
Disable / C3 Disable / C4
Disable / Sw Unoc. / Free
0 0 9
*[Configuration] Free input to be
customised (input of the extension board
BE50)
7-In.%
Custom.
3870 1-BE50.1 3871 0 0 2
*[Configuration] Free input to be
customised (input of the extension
board BE50)
2-BE50.2 3872
Liste : Not Used / S.P Offset
/ Free NTC
0 0 2
*[Configuration] Free input to be
customised (input of the extension
board BE50)
