CLIMATIC 50, user manual – Chillers ranges CL50-CHILLERS/IOM
/
0906-E
77
Main
screen
Code Description Code Description Code Description Code Unit Min Factory Max Comments
3-BE50.3 3873 0 0 2
*[Configuration] Free input to be
customised (input of the extension
board BE50)
4-BE50.4 3874 0 0 2
*[Configuration] Free input to be
customised (input of the extension
board BE50)
9-Com. 3900 1-Display 3910 1-Standard Sp 3911 Yes/No ~ Off ~
*Allows a reset of ALL set point to
standard factory settings (when
available).No possible for
configurations. and clock as there is
no factory settings for these.
2-
Master/Slave
3920 1-ID 3921 ~ 1 ~ 4 / 2
*[ Configuration ] Identification
address for the unit from 1 to 4 for
master slave operation.
2-Number 3922 ~ 1 1 4 / 2
*[ Configuration ] Number of units on the
BUS. Unit with address N°1 is always the
master
.
3-Type 3923
Liste : Not Used / Backup /
Rol.Backup / Cascade
0 0 2
*Master / Slave relationship: refer to page
7 for details
4-Outlet 3924
Liste : Not Used / M/S
Temp. / M/S Aver.
0 0 2
*Master / Slave relationship: refer to page
7 for details
5-Outside 3925
Liste : Not Used / M/S
Temp. / M/S Aver.
0 0 2
*Master / Slave relationship: refer to page
7 for details
3-BMS 3930 1-ID 3931 ~ 1 1 200
*[ Configuration ] Identification number on
the 485 Bus
2-Type 3932
Liste : Climatic / ModBus /
LonWorks/ Web
0 0 2
*[ Configuration ] Type of BMS 0 Mode
Lennox Climatic; 1 MODBUS; 2
LONWORKS
3-Baud 3933
Liste : 1200 / 2400 / 4800 /
9600 / 19200
0 3 4
BMS communication speed between
1200BDS and 19800
4-Watchdog 3934 ~ 0 0 1000
*[ BMS ] Activation of the control by a
computer or an automat
- mode BMS is activated if this value
is different from zero, This value is
decreased every second
5-BMS Unoc. 3935 On/Off ~ Off ~
*[BMS] Cancel the override unoccupied
mode
