Lennox CLIMATIC II User Manual

V2.2
-00
82
CARTE CLIMATIC ØØ KP01
Key :
J1 to J8: 3 point removable pin connectors, pitch 5.08 for 8 changeover relays
J10: 3 point removable pin connectors, pitch 5.08 for 12Vac supply and Earth
J11: 2 point removable pin connectors, pitch 3.81 for 12Vac isolated supply
J13: 3 point removable pin connectors, pitch 3.81 for card chaining
J14, J15: RJ45 connectors for I²C bus
J17, J21: 2 point removable pin connectors, pitch 3.81 for 2 analogue outputs
J18, J22: 4 point removable pin connectors, pitch 3.81 for 2 serial links
J24: 2 point removable pin connectors, pitch 3.81 for +18Vdc supply
J25: 12 point removable pin connector, pitch 3.81 for analogue inputs
J26: 12 point removable pin connector, pitch 3.81 for logic inputs
PT1, PT2: 12Vac
PT3: 0V isolated
PT6: 11V isolated
PT4: Vcc(+5V)
PT5: Gnd
PT7: Vref
PT9: Reset
PT10: Power Fail
PT11, PT13: 12Vac isolated
PT12: Clock
SW1: DIL microswitches
SW2, SW3: Configuration switches for internal or external supply to chaining link
SW4: Battery switch (on or off)
SW5: Configuration switch - type analogue input
