5
Touch the screen to turn on the backlight if it is off.
A. OPERATING MODE - touch to access the
screen that will list available modes. Selectable
modes are heat/cool, heat only, cool only, off,
emergency heat, schedule 1, schedule 2, and
schedule 3. In addition fan operation can be set
to on, auto or circulate.
B. AWAY - Selecting AWAY will allow the user to
set the heating and/or cooling mode
temperatures when away from home.
Touch cancel to exit this screen and return
to the home screen and normal system
operations.
cancel
C. Displays current time.
D. Menu - This will allow access to notifications,
performance report, schedules and
settings.
E. This allows you to set the heat-to (if enabled)
temperature. Selecting the heat-to or
temperature dial position indicator will take you
to the temperature setting detail screen. The
temperature dial will change from white to red
when heating is active.
F. This allows you to set the cool-to (if enabled)
temperature. Selecting the cool-to or
temperature dial position indicator will take
you to the temperature setting detail screen.
The dial will change from white to blue when
cooling is active.
G. Displays the current indoor temperature.
