Lennox ComfortSense 7000 series Programming And Application Guide

Page 27
ComfortSenset Touch Screen Thermostat
Action to Clear /
Recovery Condition
System Action
Display Text
(Screen2)
Display Text (Screen1)Condition
STATUS
Initial Power Up OR
recovery from power
loss of more than the
life of lithium battery
(System does not
know its Date/Time)
SET DATE/TIME
Default DATE/TIME (MON
JAN 1 12:00 PM)
Message is displayed on the
dot Part.
User has to set the current
date/time to get rid of this mes-
sage. If higher priority Remind-
er or Error message occur
then that message will be dis-
played first.
Heating (only when
system is in Heat Call)
HEATING
Date/Time
Displayed on first line. Second
line has Date/Time info on it
When call is ended OR when
higher priority reminder/error
occurs
Cooling (only when
system is in cool call)
COOLING
Date/Time
Displayed on first line. Second
line has Date/Time info on it
When call is ended OR when
higher priority reminder/error
occurs
Auto (When in heat or
cool call)
HEATING or COOLING
Date/Time
Displayed on first line. Second
line has Date/Time info on it
When call is ended OR when
higher priority reminder/error
occurs
Humidifying (only
when system is hu-
midifying)
HUMIDIFYING
Date/Time
Displayed on first line. Second
line has Date/Time info on it
When call is ended OR when
higher priority reminder/error
occurs
Dehumidifying (only
when system is in de-
humidifying)
DEHUMIDIFYING
Date/Time
Displayed on first line. Second
line has Date/Time info on it
When call is ended OR when
higher priority reminder/error
occurs
System Off SYSTEM OFF
Date/Time
Displayed on first line. Second
line has Date/Time info on it
When call is ended OR when
higher priority reminder/error
occurs
Outdoor temperature
(when selected User
settings)
OUTDOOR TEMP XXF
Date/Time
Displayed on first line. Second
line has Date/Time info on it
Is user de−selects from User
settings or higher priority re-
minder/error occurs
Indoor Humidity (when
selected from User
settings)
INDOOR RH XX%
Date/Time
Displayed on first line. Second
line has Date/Time info on it
Is user de−selects from User
settings or higher priority re-
minder/error occurs
Schedule ON (User
turns on the schedule)
SCHEDULE ON
Date/Time
Message is displayed on first
line for 3seconds.
Message will disappear after 3
seconds or if higher priority Er-
ror/Reminder occurs
Schedule OFF (User
turns off the schedule)
SCHEDULE OFF
Date/Time
Message is displayed on first
line for 3seconds.
Message will disappear after 3
seconds or if higher priority Er-
ror/Reminder occurs
Temporary Hold On
(User had set a Tem-
porary hold on set
points)
HOLD SETTING UNTIL
Date/Time
PRESS SCHED TO
RESUME
PROGRAM
Message is displayed on the
screen and system has a tem-
porary hold on temperature.
Message will disappear when
user hits SCHED or if higher
priority Error/Reminder occurs
Compressor Protec-
tion timer (5min) is
running
WAIT Message is displayed on the
screen whenever compressor
protection is running AND
cooling/heating demand exists.
Message will disappear when
compressor protection run ex-
pires OR there is no cooling or
heating demand.
FAN mode is set to
AUTO on home (fol-
low the schedule) and
ON in the current peri-
od of schedule & (sys-
tem is not heating or
cooling)
FAN ON Message is displayed on the
first line of dot matrix
The Message goes away if:
1 − User changes FAN mode from
AUTO to ON or CIRC On home
2 − User changes FAN mode in the
schedule from ON to something else
FAN mode is set to
AUTO on home (fol-
low the schedule) and
CIRC in the current
period of schedule &
(system is not heating
or cooling)
FAN CIRC Message is displayed on the
first line of dot matrix
The Message goes away if:
1 − User changes FAN mode from
AUTO to ON or CIRC On home
2 − User changes FAN mode in the
schedule from CIRC to something
else
