Lennox DAVE LENNOX SIGNATURE CBX32MV User Manual

CBX32MV / Page 22
LIQUID
LINE
SUCTION LINE
SUPPLY
AIR
OPENING
FILTER
LOW VOLTAGE INLETS
(Bottom and Right Side)
TOP VIEW
WEIV DNEWEIV TNORF
BLOWER
DETAIL OF PIPING PLATE
H
B
C
D
LIQUID
LINE
SUCTION
LINE
CONDENSATE
DRAINS (2)
(Upflow and Downflow)
CONDENSATE
DRAINS (2)
(Horizontal)
COIL
PIPING
PLATE
3/4
(19)
3/4
(19)
3/4
(19)
1-1/2
(38)
1-3/4
(44)
5-3/4
(146)
2
(51)
1-1/8 (29)
RETURN
AIR
OPENING
F
E
5/8
(16)
5/8
(16)
5/8
(16)
END VIEW
AIR
FLOW
OPTIONAL ELECTRIC HEAT
(Field Installed)
11-1/16
(281)
LINE VOLTAGE
INLETS
(Top and Right Side)
5-3/8
(137)
4-3/8
(111)
LIQUID
LINE
SUCTION LINE
SUPPLY
AIR
OPENING
FILTER
LOW VOLTAGE
INLETS
(Top and
Left Side)
TOP VIEW
FRONT VIEWEND VIEW
BLOWER
DETAIL OF PIPING PLATE
B
C
D
LIQUID
LINE
SUCTION
LINE
COIL
PIPING
PLATE
3/4
(19)
3/4
(19)
3/4
(19)
2
(51)
1-1/8 (29)
RETURN
AIR
OPENING
F
E
5/8
(16)
5/8
(16)
5/8
(16)
END VIEW
AIR
FLOW
OPTIONAL ELECTRIC HEAT
(Field Installed)
11-1/16
(281)
LINE VOLTAGE INLETS
(Bottom and Left Side)
5-3/8
(137)
4-3/8
(111)
LEFT-HAND AIR DISCHARGE
RIGHT-HAND AIR DISCHARGE
FILTER
ACCESS
FILTER
ACCESS
5-3/4
(146)
1-1/2
(38)
1-3/4
(44)
CONDENSATE
DRAINS (2)
(Horizontal)
A
5/8
(16)
G
H
A
5/8
(16)
G
1
(25)
1
(25)
Note − Units are shipped in one
piece but may be disassembled
into two separate sections for ease
of installation.
Note − Units are shipped in one
piece but may be disassembled
into two separate sections for ease
of installation.
DIMENSIONS - INCHES (MM) HORIZONTAL
Model
No.
CBX32MV-018/024 CBX32MV-024/030 CX32MV-036
CBX32MV-048
CBX32MV-060
CBX32MV-068
inch mm inch mm inch mm inch mm inch mm
A 45-1/4 1149 49-1/4 1251 51 1295 58-1/2 1486 65 1651
B 16-1/4 413 21-1/4 540 21-1/4 540 21-1/4 540 21-1/4 540
C 20-5/8 524 20-5/8 524 22-5/8 878 24-7/8 625 26-5/8 675
D 14-3/4 375 19-3/4 502 19-3/4 502 19-3/4 502 19-3/4 502
E 19 483 19 483 21 533 23 584 25 635
F 15 381 20 508 20 508 20 508 20 508
G 24-5/8 625 24-5/8 625 26-3/4 640 27-7/8 708 32-3/8 822
H 20-5/8 524 24-5/8 625 24-5/8 625 30-5/8 778 32-5/8 829
22 of 44 B17-0056
01/19/2017

Lennox DAVE LENNOX SIGNATURE CBX32MV Specifications

General

Type	Variable Speed Air Handler
Refrigerant	R-410A
Airflow	Up to 2000 CFM
Warranty	10-Year Limited Warranty
Nominal Cooling Capacity	1.5 - 5 Ton
Nominal Heating Capacity	Match with heat pump or furnace
Blower Motor	Variable Speed ECM
Filter	MERV 16
