CBX32MV / Page 24
Catalog No. − 44K15
TOP VIEW
Opening
1-5/8 (41)
SIDE VIEW
1-5/8 (41)
11-3/8
(289)
3 (76)
1-5/8
(41)
13-1/2 (343)
SUPPLY AIR
OPENING
23−1/4
(591)
20
(508)
A
B
C
Break off extended width at
pre-perforated line to fit specific
air handler application.
NOTE - Width of base includes an
additional 2 in. (51 mm) for air
handler positioning adjustment.
1
D
1
No modification required.
5/8
(16)
DIMENSIONS - INCHES (MM)
TOP VIEW
SIDE VIEW
SUPPLY
AIR
OPENING
Opening
Catalog No. - 34J72
11-3/8
(289)
3 (76)
1-5/8
(41)
13-1/2 (343)
23-1/4
(591)
15
(381)
1-5/8
(41)
22-1/8 (562)
1-5/8
(41)
5/8
(16)
Model
No.
CBX32MV-018/024 CBX32MV-024/030 CBX32MV-036
CBX32MV-048
CBX32MV-060
CBX32MV-068
in. mm in. mm in. mm in. mm in. mm
A 22-1/8 562 - - - - - - - - - - - - - - - - - - - - - - - -
B - - - - - - 22-5/8 575 - - - - - - - - - - - - - - - - - -
C - - - - - - - - - - - - 24-5/8 625 - - - - - - - - - - - -
D - - - - - - - - - - - - - - - - - - 26-5/8 676 - - - - - -
E - - - - - - - - - - - - - - - - - - - - - - - - 28-5/8 727
A
B
C
D
1
E
DOWNFLOW COMBUSTIBLE FLOORING BASE
DOWNFLOW
COMBUSTIBLE
FLOORING BASE
AIR
HANDLER
24 of 44 B17-0056
01/19/2017

Lennox DAVE LENNOX SIGNATURE CBX32MV Specifications

General

Type	Variable Speed Air Handler
Refrigerant	R-410A
Airflow	Up to 2000 CFM
Warranty	10-Year Limited Warranty
Nominal Cooling Capacity	1.5 - 5 Ton
Nominal Heating Capacity	Match with heat pump or furnace
Blower Motor	Variable Speed ECM
Filter	MERV 16
