Blower Data
EL196UH070XE36B PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High Medium-High Medium Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1445 315 1315 215 1215 165 930 85 925 75
0.10 1445 335 1275 230 1170 180 905 94 860 80
0.20 1415 345 1240 240 1125 190 870 101 800 85
0.30 1380 355 1205 250 1090 200 830 109 760 95
0.40 1345 370 1175 265 1055 210 790 117 710 105
0.50 1315 385 1150 280 1020 220 735 129 665 115
0.60 1275 390 1110 290 985 230 685 137 625 125
0.70 1210 395 1075 300 950 240 640 146 565 130
0.80 N/A N/A 1030 305 915 250 595 148 535 135
EL196UH090XE48C PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High Medium-High Medium Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1765 375 1535 250 1410 180 1315 155 1155 115
0.10 1735 390 1500 260 1365 200 1270 165 1130 125
0.20 1700 405 1465 275 1330 215 1230 175 1095 135
0.30 1660 425 1435 290 1295 225 1195 190 1055 145
0.40 1640 435 1400 300 1265 235 1165 200 1010 155
0.50 1615 450 1370 315 1230 250 1125 215 965 165
0.60 1575 465 1340 325 1190 265 1080 230 925 180
0.70 1530 470 1305 340 1150 280 1045 235 885 190
0.80 N/A N/A 1260 345 1115 285 1000 245 845 195
EL196UH110XE60C PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
$LU9ROXPH:DWWVDW'LႇHUHQW%ORZHU6SHHGV
Bottom Return Air, Side Return Air with Return Air from Both
Sides or Return Air from Bottom and One Side.
Single Side Return Airí$LUYROXPHVLQbold require Optional
Return Air Base and¿HOGIDEULFDWHGWUDQVLWLRQWRDFFRPPRGDWH
[[LQDLU¿OWHULQRUGHUWRPDLQWDLQSURSHUDLUYHORFLW\
High Med-High Medium Med-Low Low High Med-High Medium Med-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 2220 655 1975 440 1800 325 1665 390 1050 180 2180 685 1910 460 1750 345 1660 285 1430 195
0.10 2185 680 1925 460 1750 345 1625 285 1440 200 2155 705 1885 480 1720 360 1610 295 1415 205
0.20 2150 705 1880 480 1710 365 1590 300 1390 220 2130 725 1855 495 1685 380 1565 305 1380 220
0.30 2110 720 1850 495 1680 380 1560 320 1350 230 2085 745 1825 510 1655 390 1535 325 1335 230
0.40 2080 735 1810 520 1650 405 1515 330 1310 245 2060 760 1795 530 1625 405 1495 340 1295 245
0.50 2045 755 1785 530 1610 415 1470 350 1265 255 2030 775 1765 545 1585 425 1450 355 1255 265
0.60 2010 775 1740 545 1575 430 1440 370 1220 270 1995 785 1725 565 1550 435 1420 370 1205 275
0.70 1980 790 1705 565 1525 450 1400 375 1170 280 1960 795 1690 575 1505 455 1385 385 1165 290
0.80 1950 795 1670 580 1485 460 1360 390 1140 293 1895 790 1650 590 1465 470 1335 395 1120 295
TABLE 17
Allowable Heating Speeds
Model Number Red Yellow Blue Brown Black
All Models Allowed Factory Setting Allowed Allowed Not Allowed
TABLE 18
Allowable Circulation Speeds
Model Number Red Yellow Blue Brown Black
All Models Factory Setting Not Allowed Not Allowed Not Allowed Not Allowed
