7
Thermostat Installation with Wall Plate
F - Place wall plate
over holes in wall.
G - Insert wall anchors
through wall plate into wall.
H - Attach back plate
to wall plate.
I - Insert provided screws through back and wall
plates into wall anchors.
J - Attach thermostat to
back plate.
Thermostat Installation without Wall Plate
G - Place back plate over wall
anchors in wall.
F - Insert wall anchors
through wall plate into wall.
H - Insert provided screws through
back plate into wall anchors.
I - Attach thermostat to
back plate.
