COMMISSIONNING
FLEXYII_WSHP-IOM-1307-E - 27 -
STEP 7: Electrical wiring
The Recovery module is sent with a power cable and a T-lan cable :
Separate these 2 cables
(communication and power
ones) using the two holes.
Power cable
Modbus cable
