Lennox LCT240H

Page 29
508288-01 9/2022
180 CHARGING CURVE CIRCUIT 2 - NO REHEAT - ALL-ALUMINUM COIL - 581086-01
Suction Pressure (psig)
70
80
90
100
110
120
Outdoor Temperature (°F)
105°
95°
115°
85°
75°
65°
130
110 120 130 140 150 160100
180 CHARGING CURVE CIRCUIT 3 - NO REHEAT - ALL-ALUMINUM COIL - 581086-01
Suction Pressure (psig)
70
80
90
100
110
120
115 125 135 145 155
Outdoor Temperature (°F)
165 175
105°
95°
115°
85°
75°
65°
60
