Lennox LGH300S Installation Instructions

Page 2
LGH/LCH156, 180, 210, 240, 300S
LGH/LCH156 Unit Dimensions - Inches (mm) - Gas Heat Section Shown
4−1/4 (108)
4
(102)
12−3/8
(314)
BOTTOM POWER ENTRY
5 X 8 inches (127 X 203 mm)
BOTTOM SUPPL
Y
AIR OPENINGS
BOTTOM RETURN
AIR OPENING
28
(71
1)
28
(71
1)
20 (508) 20 (508)
15 (381)
60−1/2 (1537)
CENTER OF
GRAVITY
TOP VIEW
4−1/2
(114)
12−3/8
(314)
4
(102)
END VIEW
90−1/8
(2289)
28−3/4
(730)
5−3/8
(137)
3−1/4
(83)
54−1/4
(1378)
51
(1295)
91−1/8 (2315)
BASE
ELECTRICAL
INLETS
8−1/4
(210)
10−1/4
(260)
4
(102)
GAS SUPPLY INLET
(For Bottom
Gas Supply Only)
OPTIONAL
DISCONNECT
(Factory Installed)
CONDENSA
TE
DRAIN
SIDE VIEW
FORKLIFT SLOTS
(Front and Left Side Only)
LIFTING HOLES
(For Rigging
Front and Back)
107−3/4(2737)
BASE
106−1/2
(2705)
OPTIONAL
115 VOLT OUTLET
(Factory Installed Inside Unit)
FLUE
OUT LET
ALTERNATE (THRU THE BASE)
CONDENSA
TE DRAIN LOCATION
1−5/8 in. (41 mm) Diameter
18 (457)
28−3/8
(721)
5−5/8 (143)
107−3/4
(2737)
BASE
91−1/8 (2315
)
BASE
54−1/4
(1378)
SIDE
GAS SUPPLY OUTLET
