BLOWER DATA
FACTORY INSTALLED BELT DRIVE KIT SPECIFICATIONS
󰀩 Nominal
hp
Maximum
hp
Drive Kit Number RPM Range
Standard or High 2 2.30 1 535 - 725
Standard or High 2 2.30 2 
Standard 3 3.45 1 535 - 725
Standard 3 3.45 2 
High 3 3.45 3 685 - 856
High 3 3.45 4 850 - 1045
Standard 5 5.75 3 685 - 856
Standard 5 5.75 4 850 - 1045
Standard 5 5.75 5 
Standard 7.5 8.63 6 850 - 1045
Standard 7.5 8.63 7 
Standard 7.5 8.63 8 1045 - 1285
Standard 10 11.50 7 
Standard 10 11.50 10 1045 - 1285
Standard 10 11.50 11 1135 - 1365
NOTE - Using total air volume and system static pressure requirements determine from blower performance tables rpm and motor output required. Maximum usable
output of motors furnished are shown. In Canada, nominal motor output is also maximum usable motor output. If motors of comparable output are used, be sure to keep
within the service factor limitations outlined on the motor nameplate.
NOTE – Units equipped with MSAV
®
(Multi-Stage Air Volume) option are limited to a motor service factor of 1.0.
FACTORY INSTALLED OPTIONS/FIELD INSTALLED ACCESSORY AIR RESISTANCE
Air
Volume
cfm
Wet Indoor Coil
Humiditrol®
Condenser
Reheat
Coil
Gas Heat Exchanger
Economizer Filters
Horizontal
Roof Curb
156H,
180H
210H,
240H,
300S
Low/Standard
Heat
Medium
Heat
High
Heat
156H
thru
240H
300S
in. w.g. in. w.g. in. w.g. in. w.g. in. w.g. in. w.g. in. w.g. MERV 8 MERV 13 in. w.g. in. w.g.
2750 .01 .02 .01 .02 .04 .05 - - - .01 .03 .03 -
3000 .01 .02 .01 .03 .04 .05 - - - .01 .03 .04 -
3250 .01 .03 .01 .03 .05 .06 - - - .01 .04 .04 .01
3500 .01 .03 .02 .03 .05 .06 - - - .01 .04 .05 .01
3750 .01 .03 .02 .04 .06 .07 - - - .01 .04 .05 .01
4000 .02 .04 .02 .04 .06 .07 - - - .01 .04 .06 .02
4250 .02 .04 .02 .04 .06 .08 - - - .01 .05 .07 .02
4500 .02 .05 .02 .05 .07  - - - .01 .05 .07 .02
4750 .02 .05 .02 .05 .08 .10 - - - .02 .05 .08 .03
5000 .02 .05 .02 .05  .11 - - - .02 .06 .08 .03
5250 .02 .06 .03 .06 .10 .12 - - - .02 .06  .04
5500 .02 .07 .03 .06 .10 .13 - - - .02 .06 .10 .04
5750 .03 .07 .03 .06 .11 .14 - - - .02 .07 .11 .05
6000 .03 .08 .03 .07 .12 .15 - - - .03 .07 .11 .06
6250 .03 .08 .03 .07 .12 .16 .01 .03 .07 .12 .07
6500 .03  .04 .08 .13 .17 .02 .03 .08 .13 .08
6750 .04 .10 .04 .08 .14 .18 .03 .03 .08 .14 .08
7000 .04 .10 .04  .15  .04 .04 .08 .15 
7250 .04 .11 .04  .16 .20 .05 .04  .16 .10
7500 .05 .12 .05 .10 .17 .21 .06 .04  .17 .11
8000 .05 .13 .05 .11  .24  .05 .10  .13
8500 .06 .15 .05 .12 .20 .26 .11 .05 .10 .21 .15
 .07 .16 .06 .13 .23  .14 .06 .11 .24 .17
 .08 .18 .07 .14 .25 .32 .16 .07 .12 .26 
10,000 .08 .20 .07 .16 .27 .35  .07 .12  .21
10,500  .22 .08 .17 .30 .38 .22 .08 .13 .31 .24
11,000 .11 .24 .08 .18 .31 .40 .25  .14 .34 .27
