Page 18
ELECTRICAL DATA 13 TON
13 TON HIGH EFFICIENCY LGH156H4
1
Voltage - 60hz 208/230V - 3 Ph 460V - 3 Ph 575V - 3 Ph
Compressor 1 Rated Load Amps 14.5 6.3 6
Locked Rotor Amps 55 41
Compressor 2 Rated Load Amps 14.5 6.3 6
Locked Rotor Amps 55 41
Compressor 3 Rated Load Amps 14.5 6.3 6
Locked Rotor Amps 55 41
Outdoor Fan
Motors (3)
Full Load Amps
(total)
2.4
(7.2)
1.3
1
(3)
Power Exhaust
(2) 0.33 HP
Full Load Amps
(total)
2.4
(4.8)
1.3
(2.6)
1
(2)
Service Outlet 115V GFI (amps) 15 15 20
Indoor Blower
Motor
Horsepower 2 3 5 2 3 5 2 3 5
Full Load Amps 7.5 10.6 16.7 3.4 4.8 7.6 2.7 6.1
2
Maximum
Overcurrent
Protection
Unit Only 70 70 80 30 35 35 30 30 30
With (2) 0.33 HP
Power Exhaust
80 80 35 35 40 30 30 35
3
Minimum
Circuit
Ampacity
Unit Only 62 65 72 28 30 33 26 27
With (2) 0.33 HP
Power Exhaust
67 70 77 31 32 35 28 31
ELECTRICAL DATA 15 TON
15 TON HIGH EFFICIENCY LGH180H4
1
Voltage - 60hz 208/230V - 3 Ph 460V - 3 Ph 575V - 3 Ph
Compressor 1 Rated Load Amps 13.2 6.3
Locked Rotor Amps 60 41
Compressor 2 Rated Load Amps 13.2 6.3
Locked Rotor Amps 60 41
Compressor 3 Rated Load Amps 13.2 6.3
Locked Rotor Amps 60 41
Outdoor Fan
Motors (4)
Full Load Amps
(total)
2.4
1.3
(5.2)
1
(4)
Power Exhaust
(2) 0.33 HP
Full Load Amps
(total)
2.4
(4.8)
1.3
(2.6)
1
(2)
Service Outlet 115V GFI (amps) 15 15 20
Indoor Blower
Motor
Horsepower 3 5 7.5 3 5 7.5 3 5 7.5
Full Load Amps 10.6 16.7 24.2 4.8 7.6 11 6.1
2
Maximum
Overcurrent
Protection
Unit Only 70 80 100 35 40 45 25 30 35
With (2) 0.33 HP
Power Exhaust
80 100 35 40 50 30 30 40
3
Minimum
Circuit
Ampacity
Unit Only 64 71 80 31 34 38 24 27 30
With (2) 0.33 HP
Power Exhaust
68 75 85 34 37 41 26 32
NOTE - All units have a minimum Short Circuit Current Rating (SCCR) of 5000 amps.
1
Extremes of operating range are plus and minus 10% of line voltage.
2
HACR type breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
4
Factory installed circuit breaker not available.
