Page 4
LGH/LCH420, 480, 540, 600
POWER EXHAUST
DISCHARGE
(OPTIONAL)
EVAPORATOR
COILS
CONDENSATE
DRAIN
HOT GAS
REHEAT COILS
(OPTIONAL)
BURNERS
GAS VALVES (2)
CONDENSER
COILS (4)
CONTROL
BOX
COMPRESSORS (4)
CONDENSER
FANS (6)
BLOWERS
FILTERS
ELEVEN - 16 x 25 x 2”
(406 x 635 x 51mm)
OR
16 X 25 X 4”
(406 X 635 X 102mm)
ECONOMIZER
(OPTIONAL)
ENERGY RECOVERY
WHEEL (OPTIONAL)
FILTER
DRIERS
LGH420, 480, 540, 600 PARTS ARRANGEMENT
LOUVERS
(OPTIONAL)
