Lennox LGH480 User Manual

Page 3
507232-04 7/2017
LGH/LCH420, 480, 540, 600 Unit Dimensions Horizontal Airflow - In. (mm) - Gas Heat Shown
28-3/4
(730)
31-1/4
(794)
31-1/4
(794)
68
(1727)
286 (7264)
Return
Air
Opening
Supply
Air
Opening
1 in. (25 mm) Typ.
90
(2286)
Return
Air
Opening
26-1/4
(667)
Return
Air
Opening
Return
Air
Opening
157 (3988)
6 (152)
23-3/4 (603)
6-1/4
(159)
6-3/4
(171)
10-3/8
(264)
69-1/4 (1759)
Return
Air
Opening
36
(914)
40
(1016)
90
(2286)
TOP VIEW
SIDE VIEW
END VIEW
1-1/2 (38)
Optional
Outdoor Air
Hoods (2)
1-3/8 in. (35 mm) wide
gasketed seal
recessed 1-1/8 in. (29 mm)
(all 4 sides of each
return air opening)
(all 4 sides of supply
air opening)
Electric
Inlet
5-5/8
(143)
8-7/8
(225)
3-3/8
(86)
Gas
Supply
Inlet
4-7/8
(124)
13-1/4 (337)
See End View for gas
supply inlet detail
10-3/8
(264)
26-1/4
(667)
Optional Barometric
Relief Hoods
(one or two, each side).
NOTE - If only one hood
is used it is located on
the same side of unit as
the Supply Air Opening.
Optional Barometric
Relief Hoods
(one or two, each side).
NOTE - If only one hood
is used it is located on
the same side of unit as
the Supply Air Opening.
