TABLE 5
SUPPLY AIR BLOWER DRIVE COMPONENT MANUFACTURER'S NUMBERS
Drive
No.
DRIVE COMPONENTS
MOTOR PULLEY BLOWER PULLEY BLOWER BUSHING BELTS
OEM Part No. Browning No. OEM Part No. Browning No. OEM Part No. Browning No.
OEM Part
No.
Browning No.
1 P-8-2237 1VP62 X 1-1/8 78M9001 1B5V160 79M0601 B - 1-11/16 78M6401 5VX900
2 78M6901 1VP71 X 1-1/8 78M9001 1B5V160 79M0601 B - 1-11/16 78M6501 5VX930
3 100239-06 1VP71 X 1-3/8 78M9001 1B5V160 79M0601 B - 1-11/16 78M6401 5VX900
4 100239-06 1VP71 X 1-3/8 78M8801 1B5V136 79M0601 B - 1-11/16 78M6201 5VX860
5 78M7101 1VP65 X 1-3/8 78M8801 1B5V136 79M0601 B - 1-11/16 78M6101 5VX850
6 100239-05 1VP75 X 1-3/8 78M8701 1B5V124 79M0601 B - 1-11/16 78M6101 5VX850
7 78M7201 1VP71 X 1-5/8 78M8801 1B5V136 79M0601 B - 1-11/16 78M6101 5VX850
8 78M7401 1VP75 X 1-5/8 78M8701 1B5V124 79M0601 B - 1-11/16 78M5901 5VX830
9 103387-01 2VP65 X 1-5/8 103386-01 1B5V94 79M0601 B - 1-11/16 78M5601 5VX780
10 103384-01 2VP65 X 1-5/8 78M9901 2B5V110 79M0601 B - 1-11/16 78M5701 5VX800(2)
11 103384-01 2VP65 X 1-5/8 103385-01 2B5V90 79M0601 B - 1-11/16 78M5501 5VX750(2)
12 78M7801 2V68B80 X 1-7/8 78M8801 2B5V136 79M0601 B - 1-11/16 78M6101 5VX850(2)
13 78M7701 2V58B70 X 1-7/8 79M0201 2Q5V103 79M0801 Q - 1-11/16 78M5601 5VX780(2)
14 78M7801 2V68B80 X 1-7/8 78M9901 2B5V110 79M0601 B - 1-11/16 78M5801 5VX810(2)
TABLE 6
POWER EXHAUST DRIVE COMPONENT MANUFACTURER'S NUMBERS
Drive No.
DRIVE COMPONENTS
MOTOR PULLEY BLOWER PULLEY BELTS
Browning No. OEM Part No. Browning No. OEM Part No.
Browning
No.
OEM Part No.
1A 1VP60 x 1 3/8 78L5501 BK100 x 1 7/16 39L1301 BX68 88K3401
1B 1VP60 x 1 3/8 78L5501 BK100 x 1 7/16 39L1301 BX62 57A7701
2A 1VP60 x 1 3/8 78L5501 BK110 x 1 7/16 81M0401 BX70 31K9601
2B 1VP60 x 1 3/8 78L5501 BK110 x 1 7/16 81M0401 BX64 24L5001
3A 1VP56 x 1 1/8 P-8-1492 BK100 x 1 7/16 39L1301 BX68 88K3401
3B 1VP56 x 1 1/8 P-8-1492 BK100 x 1 7/16 39L1301 BX61 93J9801
4A 1VP60 x 1 1/8 41C1301 BK115 x 1 7/16 81M0501 BX71 31K9701
4B 1VP60 x 1 1/8 41C1301 BK115 x 1 7/16 81M0501 BX64 24L5001
5A 1VP56 x 7/8 P-8-1494 BK115 x 1 7/16 81M0501 BX71 31K9701
5B 1VP56 x 7/8 P-8-1494 BK115 x 1 7/16 81M0501 BX64 24L5001
6A 1VP60 x 7/8 80K5501 BK115 x 1 7/16 81M0501 BX71 31K9701
6B 1VP60 x 7/8 80K5501 BK115 x 1 7/16 81M0501 BX64 24L5001
NOTE - A drives for rear blower assembly; B drives for front blower assembly.
