Lennox LGH480 User Manual

Page 52
LGH/LCH420, 480, 540, 600
FIGURE 47
SECURE HOODS TO UNIT
SIDE VIEW
UNIT
TOP
UNIT
FLANGE
HOOD
SECURE
BOTH SIDES
OF EACH
HOOD
VERTICAL
DISCHARGE UNIT
INTAKE HOODS
HORIZONTAL
DISCHARGE UNIT
INTAKE HOODS
BAROMETRIC
RELIEF DAMPER
HOODS (1 OR 2
REQUIRED)
BAROMETRIC
RELIEF DAMPER
HOODS (1 OR 2
REQUIRED)
SECURE BOTH
SIDES OF EACH
HOOD
FIGURE 48
OUTDOOR AIR HOOD SCREEN
BACK SIDE OF HORIZONTAL DISCHARGE UNIT SHOWN
SECURE HINGE
TO UNIT WITH
FOUR SCREWS
SECURE SCREEN
TO HOOD WITH
TWO SCREWS
SCREEN
HINGE
RETURN
AIR END
OF UNIT
HOOD
