TABLE 24

HEATING, VENTILATION & SMOKE MINIMUM AND MAXIMUM CFM

Unit Heating CFM Vent CFM Smoke CFM

Model Speed Heat Code Min Default Max Min Default Max Min Default Max

LGM156U Low, Std, Med L, S, M 4500 5200 6250 800 1150 * 1950 5200 6250

LGM180U Low, Std, Med L, S, M 4500

6000 7200 800 1325 * 2250 6000 7200

LGM180U High H 5125

LGM210U Low, Std, Med L, S, M 4500

7000 8400 800 1550 * 2625 7000 8400

LGM210U High H 5125

LGM240U Low, Std, Med L, S, M 4500

8000 9600 800 1750 * 3000 8000 9600

LGM240U High H 5125

LGM300U Low, Std, Med L, S, M 4500

10000 12000 800 2200 * 3750 10000 12000

LGM300U High H 5125

LCM156U All N, E, J, K, L, P 5200 5200 6250 800 1150 * 1950 5200 6250

LCM180U All N, E, J, K, L, P 6000 6000 7200 800 1325 * 2250 6000 7200

LCM210U All N, E, J, K, L, P 6000 7000 8400 800 1550 * 2625 7000 8400

LCM240U All N, E, J, K, L, P 6000 8000 9600 800 1750 * 3000 8000 9600

LCM300U All N, E, J, K, L, P 6000 10000 12000 800 2200 * 3750 10000 12000

*Use highest value between Heating and Cooling High CFM Max.

TABLE 25

COOLING MINIMUM AND MAXIMUM CFM

Model

Cooling Low CFM Cooling High CFM

Default Min Max Default Min Max

156U 1150 800 * 4550 3250 6240

180U 1325 800 * 5250 3750 7200

210U 1550 800 * 6125 4375 8400

240U 1750 800 * 7000 5000 9600

300U 2200 800 * 8750 6250 12000

*Use Cooling High CFM Max.
