Page 7
SPECIFICATIONS 15 TON | 17.5 TON
General Data Nominal Tonnage 15 Ton 15 Ton 17.5 Ton 17.5 Ton
Model Number LGM180U4M LGM180U4V LGM210U4M LGM210U4V
Ultra-High Ultra-High Ultra-High Ultra-High
Blower Type SZVAV
(Single Zone
Variable Air Volume)
VAV
(Variable Air
Volume)
SZVAV
(Single Zone
Variable Air Volume)
VAV
(Variable Air
Volume)
Cooling
Performance
Gross Cooling Capacity - Btuh
1
Net Cooling Capacity - Btuh 172,000 172,000 200,000 200,000
1
AHRI Rated Air Flow - cfm 5250 5250 5400 5400
Total Unit Power - kW 14.3 14.3
1
IEER (Btuh/Watt) 17.5 18.8 18.0
1
EER (Btuh/Watt) 12.0 12.0 12.0 12.0
Refrigerant
Charge
Refrigerant Type R-410A R-410A R-410A R-410A
Without Reheat Circuit 1 10 lbs. 8 oz. 10 lbs. 8 oz.
Circuit 2 10 lbs. 15 oz. 10 lbs. 15 oz.
Circuit 3
Circuit 4 - - - - - -
With Reheat Circuit 1 22 lbs. 2 oz. - - - 10 lbs. 8 oz. - - -
Circuit 2 - - - 11 lbs. 0 oz. - - -
Circuit 3 - - - - - -
Circuit 4 - - - - - - - - -
Gas Heating Options Available
Variable Capacity Scroll (1)
Fixed Capacity Scroll (2)
Variable Capacity Scroll (1)
Fixed Capacity Scroll (3)
Outdoor Coils
Net face area (total) - sq. ft. 55.2 55.2 55.2 55.2
Tube diameter - in. 3/8 3/8 3/8 3/8
Number of rows 2 2 2 2
Fins per inch 20 20 20 20
Outdoor Coil
Fans
Motor - (No.) horsepower (4) 1/3 ECM (4) 1/3 ECM
Motor rpm 280-1075 280-1075
Total Motor watts 150 -1350 150 -1350
Diameter - (No.) in. (4) 24 (4) 24
Number of blades 3 3 3 3
Total Air volume - cfm
Indoor Coils Net face area (total) - sq. ft. 21.40 21.40 21.40 21.40
Tube diameter - in. 3/8 3/8 3/8 3/8
Number of rows 3 3 4 4
Fins per inch 14 14 14 14
Drain connection - No. and size (1) 1 in. FPT (1) 1 in. FPT (1) 1 in. FPT (1) 1 in. FPT
Expansion device type Balance port TXV, removable head
2
Indoor
Blower
and
Drive
Selection
Nominal motor output 3 hp, 5 hp, 7.5 hp
Max. usable motor output (US)
Motor - Drive kit number Kit 1 535-725 rpm
Kit 2
5 hp
Kit 3
Kit 4 850-1045 rpm
Kit 5
7.5 hp
Kit 6 850-1045 rpm
Kit 7
Kit 8 1045-1285 rpm
Blower wheel nominal D x W - in. (2) 15 x 15
Filters Fiberglass, disposable
Number and size - in.
Electrical characteristics
NOTE - Net capacity includes evaporator blower motor heat deduction. Gross capacity does not include evaporator blower motor heat deduction.
1
2
Using total air volume and system static pressure requirements determine from blower performance tables rpm and motor output required. Maximum usable output of
motors furnished are shown. In Canada, nominal motor output is also maximum usable motor output. If motors of comparable output are used, be sure to keep within the
service factor limitations outlined on the motor nameplate.
NOTE – Blower motor service factor = 1.0.
