General
The M0STAT120N-1 is a wired programmable
local controller for mini-split indoor units with
convenient timed schedules for daily operation.
These instructions are intended as a general
guide and do not supersede local codes in any
way. Consult authorities having jurisdiction
before installation.
Requirements
Verify the power supply has been turned o
before beginning installation. This controller
should be used only as described in this
manual.
Do not install the controller on exterior walls
(where there is unconditioned space on
opposite side of wall) or in locations where
direct sunlight may be present.
Shipping and Packing List
Item Qty
Wired Controller 1
Battery 1
Connection Cable D for MWMC,
MWHB, and MWCB wall mounted
models.
1
Connection Cable for MMDA/B,
MCFA/B, M22A and M33A/B/C
indoor units
1
Item Qty
Installation and User Information
Guide
1
Screws for securing back plate to
drywall (M3.9*25)
3
Drywall anchors for securing back
plate
3
4-pin extension cable assembly -
20 Feet (6 meters)
1
Ground screw for extension cable
(M4x8)
1
