Lennox M0STAT61Q-1 User Manual

4
4. Attach the wall plate using the provided screws. See gure 3.
Back plate
Screws (M4×20)
J-box
Back plate
Screw (M4×20)
Screws (M4×25)
Figure 3. Mount Wall Plate
5. Reattach the cover to the wall plate. See gure 4.
Figure 4. Reattach Cover to Wall Plate

Lennox M0STAT61Q-1 Specifications

General

Brand	Lennox
Model	M0STAT61Q-1
Category	Controller
Language	English
