BLOWER DATA
ML296UH045XV36B BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
“ADJUST”
Switch
Positions
Speed Switch Positions
Second Stage “HEAT” Speed - cfm Second Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 745 875 990 1005 905 1075 1210 1370
1
NORM 685 765 895 910 815 980 1120 1255
— 610 695 785 810 720 885 1020 1135
“ADJUST”
Switch
Positions
First Stage “HEAT” Speed - cfm First Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 685 765 895 910 595 760 865 980
1
NORM 620 705 800 820 540 660 785 890
— 545 625 715 725 485 600 695 790
1
Factory default jumper setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT speed position.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position - minimum 500 cfm.
BLOWER DATA
ML296UH070XV36B BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
“ADJUST”
Switch
Positions
Speed Switch Positions
Second Stage “HEAT” Speed - cfm Second Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 965 1060 1130 1255 860 1060 1215 1365
1
NORM 880 960 990 1140 810 960 1130 1265
— 810 840 890 1030 705 840 1005 1140
“ADJUST”
Switch
Positions
First Stage “HEAT” Speed - cfm First Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 940 990 1070 1195 600 740 840 970
1
NORM 830 895 965 1100 555 665 770 855
— 755 825 840 975 500 600 680 790
1
Factory default jumper setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT speed position.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position - minimum 500 cfm.
