Table 5. MLB and MPC Multi-Zone System Combinations
NOTE - For multi-zone systems, the total capacity of all indoor units must be 66% to 133% of the outdoor unit capacity.
Outdoor Unit
Model No.
Number
of
Zones
Indoor Unit
Capacity
Nominal Cooling Capacity at Rated
System Capacity (Btuh)
Nominal Heating Capacity at Rated
System Capacity (Btuh)
#1 #2 #3 #4 #5 #1 #2 #3 #4 #5 #1 #2 #3 #4 #5
MLB and
MPC048S4M
3
18K 12K 12K - - - - - - 17,000 11,000 11,000 - - - - - - 18,100 12,100 12,100 - - - - - -
24K 12K 12K - - - - - - 22,000 11,000 11,000 - - - - - - 22,900 11,500 11,500 - - - - - -
30K 12K 12K - - - - - - 26,000 10,000 10,000 - - - - - - 27,300 10,900 10,900 - - - - - -
36K 12K 12K - - - - - - 29,000 10,000 10,000 - - - - - - 31,400 10,500 10,500 - - - - - -
18K 18K 12K - - - - - - 16,000 16,000 11,000 - - - - - - 17,200 17,200 11,500 - - - - - -
24K 18K 12K - - - - - - 20,000 15,000 10,000 - - - - - - 21,800 16,400 10,900 - - - - - -
30K 18K 12K - - - - - - 24,000 14,000 10,000 - - - - - - 26,200 15,700 10,500 - - - - - -
24K 24K 12K - - - - - - 19,000 19,000 10,000 - - - - - - 21,000 21,000 10,500 - - - - - -
18K 18K 18K - - - - - - 15,000 15,000 15,000 - - - - - - 16,400 16,400 16,400 - - - - - -
24K 18K 18K - - - - - - 19,000 14,000 14,000 - - - - - - 21,000 15,700 15,700 - - - - - -
MLB and
MPC048S4M
4
18K 6K 6K 6K - - - 18,000 6,000 6,000 6,000 - - - - - - 19,400 6,500 6,500 6,500
24K 6K 6K 6K - - - 24,000 6,000 6,000 6,000 - - - - - - 25,100 6,300 6,300 6,300
30K 6K 6K 6K - - - 29,000 6,000 6,000 6,000 - - - - - - 30,100 6,100 6,100 6,100
36K 6K 6K 6K - - - 32,000 5,000 5,000 5,000 - - - - - - 33,800 5,700 5,700 5,700
18K 9K 6K 6K - - - 18,000 9,000 6,000 6,000 - - - - - - 19,100 9,600 6,400 6,400
24K 9K 6K 6K - - - 24,000 9,000 6,000 6,000 - - - - - - 24,600 9,300 6,200 6,200
30K 9K 6K 6K - - - 28,000 8,000 6,000 6,000 - - - - - - 29,200 8,800 5,900 5,900
36K 9K 6K 6K - - - 31,000 8,000 5,000 5,000 - - - - - - 32,500 8,200 5,500 5,500
12K 12K 6K 6K - - - 12,000 12,000 6,000 6,000 - - - - - - 12,900 12,900 6,500 6,500
18K 12K 6K 6K - - - 18,000 12,000 6,000 6,000 - - - - - - 18,900 12,600 6,300 6,300
24K 12K 6K 6K - - - 23,000 11,000 6,000 6,000 - - - - - - 24,100 12,100 6,100 6,100
30K 12K 6K 6K - - - 27,000 11,000 5,000 5,000 - - - - - - 28,200 11,300 5,700 5,700
36K 12K 6K 6K - - - 30,000 10,000 5,000 5,000 - - - - - - 31,000 10,400 5,200 5,200
18K 18K 6K 6K - - - 17,000 17,000 6,000 6,000 - - - - - - 18,100 18,100 6,100 6,100
24K 18K 6K 6K - - - 22,000 16,000 5,000 5,000 - - - - - - 22,600 16,900 5,700 5,700
30K 18K 6K 6K - - - 25,000 15,000 5,000 5,000 - - - - - - 25,800 15,500 5,200 5,200
24K 24K 6K 6K - - - 20,000 20,000 5,000 5,000 - - - - - - 20,700 20,700 5,200 5,200
12K 9K 9K 6K - - - 12,000 9,000 9,000 6,000 - - - - - - 12,900 9,700 9,700 6,500
18K 9K 9K 6K - - - 18,000 9,000 9,000 6,000 - - - - - - 18,900 9,500 9,500 6,300
24K 9K 9K 6K - - - 23,000 9,000 9,000 6,000 - - - - - - 24,100 9,100 9,100 6,100
30K 9K 9K 6K - - - 27,000 8,000 8,000 5,000 - - - - - - 28,200 8,500 8,500 5,700
36K 9K 9K 6K - - - 30,000 7,000 7,000 5,000 - - - - - - 31,000 7,800 7,800 5,200
12K 12K 9K 6K - - - 12,000 12,000 9,000 6,000 - - - - - - 12,800 12,800 9,600 6,400
18K 12K 9K 6K - - - 18,000 12,000 9,000 6,000 - - - - - - 18,500 12,300 9,300 6,200
24K 12K 9K 6K - - - 22,000 11,000 8,000 6,000 - - - - - - 23,400 11,700 8,800 5,900
30K 12K 9K 6K - - - 26,000 10,000 8,000 5,000 - - - - - - 27,100 10,900 8,200 5,500
36K 12K 9K 6K - - - 28,000 9,000 7,000 5,000 - - - - - - 29,300 9,800 7,400 4,900
18K 18K 9K 6K - - - 17,000 17,000 8,000 6,000 - - - - - - 17,500 17,500 8,800 5,900
24K 18K 9K 6K - - - 21,000 16,000 8,000 5,000 - - - - - - 21,700 16,300 8,200 5,500
30K 18K 9K 6K - - - 24,000 14,000 7,000 5,000 - - - - - - 24,500 14,700 7,400 4,900
12K 12K 12K 6K - - - 12,000 12,000 12,000 6,000 - - - - - - 12,600 12,600 12,600 6,300
18K 12K 12K 6K - - - 17,000 11,000 11,000 6,000 - - - - - - 18,100 12,100 12,100 6,100
24K 12K 12K 6K - - - 22,000 11,000 11,000 5,000 - - - - - - 22,600 11,300 11,300 5,700
30K 12K 12K 6K - - - 25,000 10,000 10,000 5,000 - - - - - - 25,800 10,400 10,400 5,200
