Lennox MMA048S4 User Manual

47
Table 5. MLB and MPC Multi-Zone System Combinations
NOTE - For multi-zone systems, the total capacity of all indoor units must be 66% to 133% of the outdoor unit capacity.
Outdoor Unit
Model No.
Number
of
Zones
Indoor Unit
Capacity
Nominal Cooling Capacity at Rated
System Capacity (Btuh)
Nominal Heating Capacity at Rated
System Capacity (Btuh)
#1 #2 #3 #4 #5 #1 #2 #3 #4 #5 #1 #2 #3 #4 #5
MLB and
MPC048S4M
4
18K 18K 12K 6K - - - 16,000 16,000 11,000 5,000 - - - - - - 16,900 16,900 11,300 5,700
24K 18K 12K 6K - - - 20,000 15,000 10,000 5,000 - - - - - - 20,700 15,500 10,400 5,200
9K 9K 9K 9K - - - 9,000 9,000 9,000 9,000 - - - - - - 9,700 9,700 9,700 9,700
12K 9K 9K 9K - - - 12,000 9,000 9,000 9,000 - - - - - - 12,800 9,600 9,600 9,600
18K 9K 9K 9K - - - 18,000 9,000 9,000 9,000 - - - - - - 18,500 9,300 9,300 9,300
24K 9K 9K 9K - - - 22,000 8,000 8,000 8,000 - - - - - - 23,400 8,800 8,800 8,800
30K 9K 9K 9K - - - 26,000 8,000 8,000 8,000 - - - - - - 27,100 8,200 8,200 8,200
36K 9K 9K 9K - - - 28,000 7,000 7,000 7,000 - - - - - - 29,300 7,400 7,400 7,400
12K 12K 9K 9K - - - 12,000 12,000 9,000 9,000 - - - - - - 12,600 12,600 9,500 9,500
18K 12K 9K 9K - - - 17,000 11,000 9,000 9,000 - - - - - - 18,100 12,100 9,100 9,100
24K 12K 9K 9K - - - 22,000 11,000 8,000 8,000 - - - - - - 22,600 11,300 8,500 8,500
30K 12K 9K 9K - - - 25,000 10,000 7,000 7,000 - - - 25,800 10,400 7,800 7,800 - - -
18K 18K 9K 9K - - - 16,000 16,000 8,000 8,000 - - - 16,900 16,900 8,500 8,500 - - -
24K 18K 9K 9K - - - 20,000 15,000 7,000 7,000 - - - 20,700 15,500 7,800 7,800 - - -
12K 12K 12K 9K - - - 12,000 12,000 12,000 9,000 - - - 12,300 12,300 12,300 9,300 - - -
18K 12K 12K 9K - - - 17,000 11,000 11,000 8,000 - - - 17,500 11,700 11,700 8,800 - - -
24K 12K 12K 9K - - - 21,000 10,000 10,000 8,000 - - - 21,700 10,900 10,900 8,200 - - -
30K 12K 12K 9K - - - 24,000 9,000 9,000 7,000 - - - 24,500 9,800 9,800 7,400 - - -
18K 18K 12K 9K - - - 16,000 16,000 10,000 8,000 - - - 16,300 16,300 10,900 8,200 - - -
24K 18K 12K 9K - - - 19,000 14,000 9,000 7,000 - - - 19,600 14,700 9,800 7,400 - - -
12K 12K 12K 12K - - - 11,000 11,000 11,000 11,000 - - - 12,100 12,100 12,100 12,100 - - -
18K 12K 12K 12K - - - 16,000 11,000 11,000 11,000 - - - 16,900 11,300 11,300 11,300 - - -
24K 12K 12K 12K - - - 20,000 10,000 10,000 10,000 - - - 20,700 10,400 10,400 10,400 - - -
18K 18K 12K 12K - - - 15,000 15,000 10,000 10,000 - - - 15,500 15,500 10,400 10,400 - - -
5
9K 6K 6K 6K 6K 9,000 6,000 6,000 6,000 6,000 10,000 7,000 7,000 7,000 7,000
12K 6K 6K 6K 6K 12,000 6,000 6,000 6,000 6,000 13,000 6,000 6,000 6,000 6,000
18K 6K 6K 6K 6K 18,000 6,000 6,000 6,000 6,000 19,000 6,000 6,000 6,000 6,000
24K 6K 6K 6K 6K 24,000 6,000 6,000 6,000 6,000 25,000 6,000 6,000 6,000 6,000
30K 6K 6K 6K 6K 28,000 6,000 6,000 6,000 6,000 29,000 5,000 5,000 5,000 5,000
36K 6K 6K 6K 6K 31,000 5,000 5,000 5,000 5,000 32,000 5,000 5,000 5,000 5,000
9K 9K 6K 6K 6K 9,000 9,000 6,000 6,000 6,000 10,000 10,000 6,000 6,000 6,000
12K 9K 6K 6K 6K 12,000 9,000 6,000 6,000 6,000 13,000 10,000 6,000 6,000 6,000
18K 9K 6K 6K 6K 18,000 9,000 6,000 6,000 6,000 19,000 9,000 6,000 6,000 6,000
24K 9K 6K 6K 6K 23,000 9,000 6,000 6,000 6,000 24,000 9,000 6,000 6,000 6,000
30K 9K 6K 6K 6K 27,000 8,000 5,000 5,000 5,000 28,000 8,000 5,000 5,000 5,000
36K 9K 6K 6K 6K 29,000 7,000 5,000 5,000 5,000 31,000 7,000 5,000 5,000 5,000
12K 12K 6K 6K 6K 12,000 12,000 6,000 6,000 6,000 13,000 13,000 6,000 6,000 6,000
18K 12K 6K 6K 6K 18,000 12,000 6,000 6,000 6,000 18,000 12,000 6,000 6,000 6,000
24K 12K 6K 6K 6K 22,000 11,000 6,000 6,000 6,000 23,000 11,000 5,000 5,000 5,000
30K 12K 6K 6K 6K 26,000 10,000 5,000 5,000 5,000 27,000 10,000 5,000 5,000 5,000
18K 18K 6K 6K 6K 17,000 17,000 6,000 6,000 6,000 17,000 17,000 5,000 5,000 5,000
24K 18K 6K 6K 6K 21,000 16,000 5,000 5,000 5,000 21,000 16,000 5,000 5,000 5,000
