Table 5. MLB and MPC Multi-Zone System Combinations
NOTE - For multi-zone systems, the total capacity of all indoor units must be 66% to 133% of the outdoor unit capacity.
Outdoor Unit
Model No.
Number
of
Zones
Indoor Unit
Capacity
Nominal Cooling Capacity at Rated
System Capacity (Btuh)
Nominal Heating Capacity at Rated
System Capacity (Btuh)
#1 #2 #3 #4 #5 #1 #2 #3 #4 #5 #1 #2 #3 #4 #5
MLB and
MPC048S4M
5
9K 9K 9K 6K 6K 9,000 9,000 9,000 6,000 6,000 10,000 10,000 10,000 6,000 6,000
12K 9K 9K 6K 6K 12,000 9,000 9,000 6,000 6,000 13,000 9,000 9,000 6,000 6,000
18K 9K 9K 6K 6K 18,000 9,000 9,000 6,000 6,000 18,000 9,000 9,000 6,000 6,000
24K 9K 9K 6K 6K 22,000 8,000 8,000 6,000 6,000 23,000 8,000 8,000 5,000 5,000
30K 9K 9K 6K 6K 26,000 8,000 8,000 5,000 5,000 27,000 8,000 8,000 5,000 5,000
12K 12K 9K 6K 6K 12,000 12,000 9,000 6,000 6,000 12,000 12,000 9,000 6,000 6,000
18K 12K 9K 6K 6K 17,000 12,000 9,000 6,000 6,000 18,000 12,000 9,000 6,000 6,000
24K 12K 9K 6K 6K 22,000 11,000 8,000 5,000 5,000 22,000 11,000 8,000 5,000 5,000
30K 12K 9K 6K 6K 24,000 10,000 7,000 5,000 5,000 26,000 10,000 7,000 5,000 5,000
18K 18K 9K 6K 6K 16,000 16,000 8,000 5,000 5,000 17,000 17,000 8,000 5,000 5,000
24K 18K 9K 6K 6K 20,000 15,000 7,000 5,000 5,000 21,000 15,000 7,000 5,000 5,000
12K 12K 12K 6K 6K 12,000 12,000 12,000 6,000 6,000 12,000 12,000 12,000 6,000 6,000
18K 12K 12K 6K 6K 17,000 11,000 11,000 6,000 6,000 17,000 11,000 11,000 5,000 5,000
24K 12K 12K 6K 6K 21,000 10,000 10,000 5,000 5,000 21,000 10,000 10,000 5,000 5,000
18K 18K 12K 6K 6K 16,000 16,000 10,000 5,000 5,000 16,000 16,000 10,000 5,000 5,000
9K 9K 9K 9K 6K 9,000 9,000 9,000 9,000 6,000 9,000 9,000 9,000 9,000 6,000
12K 9K 9K 9K 6K 12,000 9,000 9,000 9,000 6,000 12,000 9,000 9,000 9,000 6,000
18K 9K 9K 9K 6K 17,000 9,000 9,000 9,000 6,000 18,000 9,000 9,000 9,000 6,000
24K 9K 9K 9K 6K 22,000 8,000 8,000 8,000 5,000 22,000 8,000 8,000 8,000 5,000
30K 9K 9K 9K 6K 24,000 7,000 7,000 7,000 5,000 26,000 7,000 7,000 7,000 5,000
12K 12K 9K 9K 6K 12,000 12,000 9,000 9,000 6,000 12,000 12,000 9,000 9,000 6,000
18K 12K 9K 9K 6K 17,000 11,000 8,000 8,000 6,000 17,000 11,000 8,000 8,000 5,000
24K 12K 9K 9K 6K 21,000 10,000 8,000 8,000 5,000 21,000 10,000 8,000 8,000 5,000
18K 18K 9K 9K 6K 16,000 16,000 8,000 8,000 5,000 16,000 16,000 8,000 8,000 5,000
12K 12K 12K 9K 6K 12,000 12,000 12,000 9,000 6,000 12,000 12,000 12,000 9,000 6,000
18K 12K 12K 9K 6K 16,000 11,000 11,000 8,000 5,000 17,000 11,000 11,000 8,000 5,000
24K 12K 12K 9K 6K 20,000 10,000 10,000 7,000 5,000 21,000 10,000 10,000 7,000 5,000
12K 12K 12K 12K 6K 11,000 11,000 11,000 11,000 6,000 11,000 11,000 11,000 11,000 5,000
18K 12K 12K 12K 6K 16,000 10,000 10,000 10,000 5,000 16,000 10,000 10,000 10,000 5,000
9K 9K 9K 9K 9K 9,000 9,000 9,000 9,000 9,000 9500 9500 9500 9500 9500
12K 9K 9K 9K 9K 12,000 9,000 9,000 9,000 9,000 12,000 9,000 9,000 9,000 9,000
18K 9K 9K 9K 9K 17,000 8,000 8,000 8,000 8,000 17,000 8,000 8,000 8,000 8,000
24K 9K 9K 9K 9K 21,000 8,000 8,000 8,000 8,000 21,000 8,000 8,000 8,000 8,000
12K 12K 9K 9K 9K 12,000 12,000 9,000 9,000 9,000 12,000 12,000 9,000 9,000 9,000
18K 12K 9K 9K 9K 16,000 11,000 8,000 8,000 8,000 17,000 11,000 8,000 8,000 8,000
24K 12K 9K 9K 9K 20,000 10,000 7,000 7,000 7,000 21,000 10,000 7,000 7,000 7,000
12K 12K 12K 9K 9K 11,000 11,000 11,000 8,000 8,000 11,000 11,000 11,000 8,000 8,000
18K 12K 12K 9K 9K 16,000 10,000 10,000 8,000 8,000 16,000 10,000 10,000 8,000 8,000
12K 12K 12K 12K 9K 11,000 11,000 11,000 11,000 8,000 11,000 11,000 11,000 11,000 8,000
12K 12K 12K 12K 12K 10,000 10,000 10,000 10,000 10,000 10,000 10,000 10,000 10,000 10,000
