60
MLB048S4M / MPC048S4M
Number of Zones and Outdoor Unit Connection Sizes
NOTE - Letter = Indoor Unit Zone Connection on Outdoor Unit
Zone 1 (A) Zone 2 (B) Zone 3 (C) Zone 4 (D) Zone 5 (E)
1/4 in. liq + 1/2 in. gas 1/4 in. liq + 1/2 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas
024 012 009 009 - - -
030 012 009 009 - - -
018 018 009 009 - - -
024 018 009 009 - - -
012 012 012 009 - - -
018 012 012 009 - - -
024 012 012 009 - - -
030 012 012 009 - - -
018 018 012 009 - - -
024 018 012 009 - - -
012 012 012 012 - - -
018 012 012 012 - - -
024 012 012 012 - - -
018 018 012 012 - - -
009 006 006 006 006
012 006 006 006 006
018 006 006 006 006
024 006 006 006 006
030 006 006 006 006
009 009 006 006 006
012 009 006 006 006
018 009 006 006 006
024 009 006 006 006
030 009 006 006 006
012 012 006 006 006
018 012 006 006 006
024 012 006 006 006
030 012 006 006 006
018 018 006 006 006
024 018 006 006 006
009 009 009 006 006
012 009 009 006 006
018 009 009 006 006
024 009 009 006 006
030 009 009 006 006
012 012 009 006 006
018 012 009 006 006
024 012 009 006 006
030 012 009 006 006
018 018 009 006 006
024 018 009 006 006
LEGEND:
CLEAR = No adaptors required.
GRAY = 3/8 x 1/2 in. gas pipe adaptor is required for line set connection to outdoor unit (furnished with outdoor unit).
BLACK = 1/4 x 3/8 in. liquid pipe adaptor is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).
1/2 x 5/8 in. gas pipe adaptor is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).
