Lennox MMA048S4 User Manual

61
MLB048S4M / MPC048S4M
Number of Zones and Outdoor Unit Connection Sizes
NOTE - Letter = Indoor Unit Zone Connection on Outdoor Unit
Zone 1 (A) Zone 2 (B) Zone 3 (C) Zone 4 (D) Zone 5 (E)
1/4 in. liq + 1/2 in. gas 1/4 in. liq + 1/2 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas
012 012 012 006 006
018 012 012 006 006
024 012 012 006 006
018 018 012 006 006
009 009 009 009 006
012 009 009 009 006
018 009 009 009 006
024 009 009 009 006
030 009 009 009 006
012 012 009 009 006
018 012 009 009 006
024 012 009 009 006
018 018 009 009 006
012 012 012 009 006
018 012 012 009 006
024 012 012 009 006
012 012 012 012 006
018 012 012 012 006
009 009 009 009 009
012 009 009 009 009
018 009 009 009 009
024 009 009 009 009
012 012 009 009 009
018 012 009 009 009
024 012 009 009 009
012 012 012 009 009
018 012 012 009 009
012 012 012 012 009
012 012 012 012 012
LEGEND:
CLEAR = No adaptors required.
GRAY = 3/8 x 1/2 in. gas pipe adaptor is required for line set connection to outdoor unit (furnished with outdoor unit).
BLACK = 1/4 x 3/8 in. liquid pipe adaptor is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).
1/2 x 5/8 in. gas pipe adaptor is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).
