Lennox SCH120 User Manual

Page 24
BLOWER DATA DIRECT DRIVE | 3 - 5 TON
SCH036H / SCH060H BLOWER PERFORMANCE NOTE - Blower Table Includes Resistance For Base Unit With Electric Heat, Wet Indoor Coil And Air Filters In Place. NOTE - MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT:
SCH036H - 1020 CFM SCH060H - 1650 CFM
Air
Volume
cfm
EXTERNAL STATIC PRESSURE - In. w.g.
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2 1.3 1.4
RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts
900 1214 116 1294 144 1371 170 1444 194 1513 218 1578 240 1640 262 1699 283 1754 303 1808 322 1859 341 1911 360 1962 382 2014 405
1000 1308 144 1388 171 1463 196 1534 220 1601 243 1664 266 1723 288 1780 310 1834 331 1887 352 1938 373 1989 395 2040 419 2091 445
1100 1407 172 1485 198 1558 223 1627 247 1691 271 1752 294 1809 317 1864 339 1916 362 1968 385 2018 409 2068 434 2119 460 2169 489
1200 1512 201 1587 227 1657 252 1723 277 1784 301 1842 325 1897 349 1950 373 2001 398 2051 423 2101 449 2150 476 2199 505 2249 536 1300 1623 232 1693 258 1759 284 1822 309 1880 335 1935 360 1988 386 2039 412 2089 438 2138 466 2186 494 2234 524 2282 554 2329 586 1400 1738 266 1803 293 1865 320 1923 347 1979 373 2031 401 2082 428 2131 456 2179 485 2227 514 2274 545 2320 575 2366 607 2411 641 1500 1855 305 1915 333 1973 361 2028 389 2080 418 2130 447 2178 477 2226 507 2273 537 2318 568 2363 600 2408 632 2451 665 2495 699 1600 1973 349 2029 379 2083 408 2134 438 2183 469 2231 500 2277 531 2323 563 2368 595 2412 627 2455 660 2497 693 2539 727 2579 762 1700 2090 399 2143 430 2193 462 2241 494 2287 526 2333 558 2377 591 2421 624 2464 658 2506 691 2547 725 2588 759 2627 794 2666 829 1800 2206 456 2255 488 2303 522 2348 555 2392 589 2436 623 2478 657 2520 691 2561 725 2601 760 2640 795 2679 830 2716 865 2753 901 1900 2321 519 2368 553 2412 588 2455 622 2498 657 2539 692 2579 727 2619 762 2658 798 2696 833 2734 869 2770 905 2806 941 2841 978 2000 2435 589 2479 624 2521 660 2562 695 2602 731 2642 767 2680 803 2718 839 2755 875 2791 911 2827 947 2862 984 2896 1021 2931 1058 2100 2547 665 2589 701 2629 737 2668 774 2706 810 2744 847 2780 883 2816 919 2851 956 2886 992 2920 1029 2954 1066 2987 1103 3021 1140 2200 2659 746 2698 783 2736 820 2773 857 2809 894 2844 931 2879 967 2913 1003 2947 1040 2980 1076 3013 1112 3046 1149 3080 1185 3113 1221 2300 2770 834 2806 871 2842 908 2877 945 2911 981 2945 1017 2978 1053 3010 1089 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2400 2879 925 2913 962 2947 999 2980 1035 3012 1070 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2500 2987 1020 3019 1055 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
