Page 25
BLOWER DATA BELT DRIVE | 10 TON
SCH120HM BLOWER PERFORMANCE
NOTE - Blower Table Includes Resistance For Base Unit With Electric Heat, Wet Indoor Coil And Air Filters In Place.
NOTE - MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT - 3800 CFM.
See Blower Motor / Drive Kit Table on page 27 for Motor HP and Drive Kit RPM Ranges Available.
Air
Volume
cfm
EXTERNAL STATIC PRESSURE - In. w.g.
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2 1.3
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2000 418 0.26 453 0.33 490 0.41 530 0.48 573 0.55 617 0.62 658 0.68 697 0.76 734 0.84 767 0.93 797 1.01 825 1.09 852 1.17
2200 430 0.34 465 0.42 502 0.49 543 0.56 586 0.63 630 0.70 671 0.78 709 0.86 745 0.95 778 1.04 807 1.12 835 1.21 863 1.29
2400 444 0.44 478 0.50 516 0.57 557 0.65 601 0.72 644 0.80 683 0.88 721 0.97 757 1.07 789 1.16 818 1.25 847 1.33 875 1.41
2600 458 0.53 493 0.60 530 0.67 572 0.74 616 0.82 658 0.91 697 1.00 734 1.09 769 1.19 801 1.29 830 1.38 859 1.46 888 1.55
2800 473 0.63 508 0.70 547 0.77 589 0.85 632 0.93 673 1.03 711 1.13 747 1.23 781 1.33 813 1.43 843 1.52 872 1.60 902 1.69
3000 489 0.74 525 0.81 564 0.89 607 0.97 649 1.06 688 1.16 725 1.27 761 1.38 795 1.48 826 1.58 857 1.66 887 1.75 918 1.84
3200 506 0.86 543 0.93 583 1.01 625 1.10 666 1.20 703 1.31 740 1.42 775 1.53 809 1.64 841 1.73 871 1.82 902 1.91 934 2.01
3400 525 0.99 563 1.07 603 1.15 644 1.24 682 1.36 719 1.48 755 1.59 790 1.70 824 1.80 856 1.90 887 1.99 919 2.08 951 2.18
3600 545 1.13 583 1.21 623 1.30 662 1.41 699 1.53 735 1.65 771 1.77 806 1.87 840 1.97 872 2.07 903 2.16 936 2.25 969 2.36
3800 566 1.28 604 1.36 643 1.46 679 1.58 715 1.71 752 1.84 788 1.95 823 2.06 856 2.16 889 2.25 921 2.34 954 2.43 987 2.54
4000 587 1.44 625 1.53 661 1.64 697 1.78 733 1.91 770 2.03 806 2.15 841 2.25 874 2.34 906 2.43 938 2.52 971 2.61 1005 2.71
4200 609 1.60 645 1.71 680 1.85 715 1.99 751 2.12 788 2.24 825 2.35 859 2.44 892 2.53 924 2.62 957 2.71 989 2.80 1023 2.89
4400 629 1.79 664 1.92 698 2.07 734 2.21 771 2.34 808 2.45 844 2.55 878 2.64 911 2.73 943 2.81 975 2.89 1008 2.98 1041 3.08
4600 650 2.00 683 2.15 717 2.30 753 2.44 791 2.56 829 2.66 864 2.76 897 2.84 930 2.92 962 3.00 994 3.08 1026 3.17 1060 3.26
4800 669 2.23 702 2.39 737 2.55 774 2.67 813 2.78 850 2.88 884 2.97 917 3.05 949 3.12 981 3.20 1013 3.28 1045 3.36 1079 3.45
NOTE - Multi-Stage Air Volume drive is capable of 350 - 1050 rpm.
