Page 29
Troubleshooting: Burner starts and fires, but short cycles (too little heat)
Source Procedure Causes Correction
Thermostat Check thermostat.
Heat anticipator set too low Correct heat anticipator setting.
Vibration at thermostat Correct source of vibration.
Thermostat in the path of a
warm air draft
Shield thermostat from draft or
relocate.
Limit Control
Connect voltmeter between line
voltage connections to primary
control (black & white leads). If
burner cycles due to power inter
ruption, it is cycling on limit.
Dirty furnace air filters Clean or replace filter.
Temperature rise too high
Check fo proper nozzle size.
Replace nozzle, if necessary.
Check for restrictions and re
move, if necessary.
Check speed tap jumper and
make sure it is still in factory
position.
Blower motor seized or burned
out
Replace motor.
Blower wheel dirty Clean blower wheel.
Wrong motor rotation Replace motor.
Restrictions in return or supply
air system
Correct cause of restriction.
Power
If voltage fluctuates, fault is in the
power source. Recheck voltage
at the power source.
Loose wiring connection Locate and secure connection.
Low or fluctuating line voltage Call power company.
Troubleshooting: Burner runs continuously (too much heat).
Source Procedure Causes Correction
Thermostat
Disconnect
thermostat
wires at the pri
mary control.
If burner turns
off, fault is in
the thermostat
circuit.
Shorted or welded thermostat
contacts
Repair or replace the thermo
stat.
Stuck thermostat bimetal
Clear obstruction or replace
thermostat.
Thermostat not level Level thermostat.
Shorted thermostat wires Repair short or replace wires.
Thermostat out of calibration Replace thermostat.
Thermostat in cold draft
Correct draft or relocate the
thermostat.
Primary control
If burner does
not turn off,
fault is in the
primary control.
Failed primary control Replace the primary control.
