Lennox Signature XP21 Series

Page 3
XP21
Electrical Data
208/230V−60 Hz−1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum
Over−
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM 1−Stage
Nominal
RPM 2−Stage
Full Load
Amps (FLA)
XP21−024−230−01,
−02, −03, −04, −05
25 14.9 10.3 51.0 1/3 430 500 2.0
XP21−024−230−05 25 16.6 11.7 58.0 1/3 430 500 2.0
208/230V−60 Hz−1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum
Over−
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM 1−Stage
Nominal
RPM 2−Stage
Full Load
Amps (FLA)
XP21−036−230−01,
−02, −03
35 22.9 16.7 82.0 1/3 525 600 2.0
XP21−036−230−04 35 21.1 15.3 83.0 1/3 525 600 2.0
208/230V−60 Hz−1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum
Over−
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM 1−Stage
Nominal
RPM 2−Stage
Full Load
Amps (FLA)
XP21−048−230−01,
−02, −03
45 28.5 21.2 96.0 1/3 600 675 2.0
XP21−048−230−04 45 28.5 21.2 104.0 1/3 600 675 2.0
208/230V−60 Hz−1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum
Over−
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM 1−Stage
Nominal
RPM 2−Stage
Full Load
Amps (FLA)
XP21−060−230−01 50 34.1 25.7 118.0 1/3 625 700 2.0
XP21−060−230−02,
−03
50 30.9 23.1 118.0 1/3 625 700 2.0
XP21−060−230−04 60 38.0 28.8 153.0 1/3 625 700 2.0
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
