Page 4
XP21
Unit Dimensions −− Inches (mm)
39−1/2
(1003)
1 (25)
LIQUID LINE
INLET
SIDE VIEW
ACCESS VIEW
DISCHARGE AIR
4−5/8
(117)
BASE WITH ELONGATED LEGS
16−7/8
(429)
8−3/4
(222)
26−7/8
(683)
3−3/4 (95)
30−3/4
(781)
3−1/8
(79)
SUCTION LINE
INLET
UNIT SUPPORT
FEET
35−1/2
(902)
18−1/2
(470)
8 (203)
4−1/2
(114)
ELECTRICAL INLET
(HIGH VOLTAGE)
37 (940) (−024 AND −036)
SOLAR MODULE
WIRING
ELECTRICAL INLET
(CONTROL WIRING −
LOW VOLTAGE)
47 (1194) (−048 AND −060)
