VVCA048H4, VVCA054H4
Description
Input
Blower
Motor
Full
Load
Amps
2
Minimum
Circuit
Ampacity
3
Maximum
Overcurrent
Protection
5
Single Point
Power Source
Blower Speed
Volt kW
1
Btuh Ckt 1 Ckt 2 Ckt 1 Ckt 2
2
Minimum
Circuit
Ampacity
3
Maximum
Overcurrent
Protection
Low Medium High
5 kW V8EH0050P-1P
(13P59)
208 3.8 12,800 4.2 28.3 - - -
4
30 - - - - - - - - - • • •
220 4.2 14,300 4.2 29.3 - - -
4
30 - - - - - - - - - • • •
230 4.6 15,700 4.2 30.3 - - - 35 - - - - - - - - - • • •
240 5.0 17,100 4.2 31.3 - - - 35 - - - - - - - - - • • •
7.5 kW V8EH0080P-1P
(13P63)
208 5.6 19,200 4.2 39.3 - - -
4
40 - - - - - - - - - • • •
220 6.3
21,500 4.2 41.3 - - - 45 - - - - - - - - - • • •
230 6.9 23,500 4.2 42.3 - - - 45 - - - - - - - - - • • •
240 7.5 25,600 4.2 44.3 - - - 45 - - - - - - - - - • • •
10 kW V8EH0100P-1P
(13P64)
208 7.5 25,600 4.2 50.3 - - - 60 - - - - - - - - - • • •
220 8.4 28,700 4.2 53.3 - - - 60 - - - - - - - - - • • •
230 9.2 31,400 4.2 55.3 - - - 60 - - - - - - - - - • • •
240 10.0 34,100 4.2 57.3 - - - 60 - - - - - - - - - • • •
15 kW V8EH0150P-1P
(13P75)
208 11.3 38,400 4.2 50.3 23 60
4
25 73.3 80
6
- - - • •
220 12.6 43,000 4.2 53.3 24 60
4
25 77.3 80
6
- - - • •
230 13.8 47,000
4.2 55.3 25 60
4
25 80.3 90
6
- - - • •
240 15.0 51,000 4.2 57.3 26 60 30 83.3 90
6
- - - • •
20 kW V8EH0200P-1P
(13P76)
208 15.0 51,200 4.2 50.3 45 60
4
50 95.3 100
6
- - - • •
220 16.8 57,300 4.2 53.3 48 60
4
50 101.3 110
6
- - - • •
230 18.4 62,700 4.2 55.3 50 60
4
50 105.3 110
6
- - - • •
240 20.0 68,200 4.2 57.3 52 60 60 109.3 110
6
- - - • •
ELECTRIC HEAT DATA 036-054
VVCA036H4
Description
Input Blower Motor
Full Load
Amps
2
Minimum
Circuit
Ampacity
3
Maximum
Overcurrent
Protection
Blower Speed
Volt kW
1
Btuh Low Medium High
5 kW V8EH0050P-1P (13P59) 208 3.8 12,800 4.2 28.3
4
30 • • •
220 4.2 14,300 4.2 29.3
4
30 • • •
230 4.6 15,700 4.2 30.3 35 • • •
240 5.0 17,100 4.2 31.3 35 • • •
7.5 kW V8EH0080P-1P (13P63) 208 5.6 19,200 4.2 39.3
4
40 • • •
220 6.3 21,500 4.2 41.3 45 • • •
230 6.9 23,500 4.2 42.3 45 • • •
240 7.5 25,600 4.2 44.3 45 • • •
10 kW V8EH0100P-1P (13P64) 208 7.5 25,600 4.2 50.3 60
6
- - - • •
220 8.4 28,700 4.2 53.3 60
6
- - - • •
230 9.2 31,400 4.2 55.3 60
6
- - - • •
240 10.0 34,100 4.2 57.3 60
6
- - - • •
REPLACEMENT CIRCUIT BREAKERS
Voltage Description Catalog No.
208/240V - 1
Phase
25 amp, 2 pole 41K13
30 amp, 2 pole 17K70
40 amp, 2 pole 49K14
50 amp, 2 pole 41K12
NOTE - Circuit 1 Minimum Circuit Ampacity includes the Blower
Motor Full Load Amps.
1
Electric heater capacity only - does not include additional blower motor heat
capacity.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse
and disconnect size requirements. Use wires suitable for at least 167°F.
3
HACR type breaker or fuse.
4
Bold text indicates that the circuit breaker on CB” circuit breaker models must
be replaced with size noted. See Table on page <?>.
5
Single point power source breaker for unit with 15 and 20 kW electric heat is
not furnished and must be eld provided.
6
Do not operate fan on low speed when V8EH Electric Heat Kit is used with
VVCA air handler.
