Lennox XC21 Engineering Data

XC21 - 2 to 5 Ton Air Conditioner / Page 13
*TXV SUBSTITUTIONS
Indoor Coils/Air Handlers with factory installed expansion
valves that require eld replacement
Model No.
Indoor Coil or Air
Handler
Order No.
XC21-024 C33-44 37L51
XC21-024 CBX32M-042 37L51
XC21-024 CX34-42 37L51
XC21-036 C33-44 37L51
XC21-036 CBX27UH-036 37L51
XC21-036 CBX27UH-042 37L51
XC21-036 CBX32M-042 37L51
XC21-036 CBX32M-048 37L51
XC21-036 CBX32MV-048 37L51
XC21-036 CBX40UHV-042 37L51
XC21-036 CBX40UHV-048 37L51
XC21-036 CX34-42 37L51
XC21-036 CX34-44/48 37L51
XC21-036 CX34-49 37L51
XC21-036 CX34-50/60C 37L51
XC21-036 CX34-62 37L51
XC21-048 CBX32M-036 91M02
XC21-048 CBX32MV-036 91M02
XC21-048 CBX40UHV-036 91M02
XC21-048 CX34-44/48 91M02
XC21-060 CX34-44/48 91M02
*Factory installed expansion valve on the indoor coil or air handler shown
must be replaced with the expansion valve listed (ordered separately).
TXV USAGE
Model No. Order No.
XC21-024 37L51
XC21-036 37L51
XC21-048 91M02
XC21-060 91M02
CX34 upow coils and all Lennox air handlers (except CB26UH “R”) are
shipped with a factory installed TXV. In most cases, no change out of the valve
is needed.
If a change out is required it will be listed in the “TXV SUBSTITUTIONS” table.
The correct TXV must be ordered and eld installed. C33 coils and all horizontal
and downow coils are shipped without a TXV. The TXV must be ordered and
eld installed.
MOST POPULAR MATCHES
Outdoor Unit
Model No.
Indoor Unit
Model No
XC21-024
CBX32MV-036
XC21-036 CBX32MV-048
XC21-048 CBX32MV-048
XC21-060 CBX32MV-060

Lennox XC21 Specifications

General

SEER Rating	up to 21.00
Sound Rating	as low as 69 dB
Refrigerant	R-410A
Energy Star Certified	Yes
Compressor Type	Two-Stage
Cooling Capacity (BTU/h)	24000-54000
Warranty	10-Year Limited Warranty on compressor
