Lennox XC21 Engineering Data

XC21 - 2 to 5 Ton Air Conditioner / Page 35
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC21-060-230 TXV 57,500 16.00 12.00 CH33-60D SLP98UH135V60D 4261805
XC21-060-230 TXV 57,500 14.50 11.70 CH33-60D 4261735
XC21-060-230 TXV 58,500 16.00 12.20 CH33-62D G61MPV-60D-135 4261775
XC21-060-230 TXV 58,000 16.00 12.50 CH33-62D SL280UH135V60D 4261774
XC21-060-230 TXV 58,500 16.00 12.20 CH33-62D SLP98UH135V60D 4261806
XC21-060-230 TXV 58,000 14.70 11.70 CH33-62D 4261736
XC21-060-230 TXV 54,500 15.00 11.20 CR33-48 SL280DF090V60C 4261829
XC21-060-230 TXV 54,500 15.20 11.50 CR33-48 SL280DF110V60C 4261830
XC21-060-230 TXV 53,500 14.70 11.20 CR33-48 SLP98DF090V60C 4261833
XC21-060-230 TXV 53,500 14.70 11.20 CR33-48 SLP98DF110V60C 4261834
XC21-060-230 TXV 56,500 15.70 11.70 CR33-50/60 SL280DF090V60C 4261831
XC21-060-230 TXV 57,000 15.70 12.00 CR33-50/60 SL280DF110V60C 4261832
XC21-060-230 TXV 56,000 15.50 11.70 CR33-50/60 SLP98DF090V60C 4261835
XC21-060-230 TXV 56,000 15.50 11.70 CR33-50/60 SLP98DF110V60C 4261836
XC21-060-230 TXV 57,000 15.50 12.00 CR33-60 G61MPV-60D-135 4261765
XC21-060-230 TXV 56,500 14.50 11.50 CR33-60 4261730
XC21-060-230 TXV 58,500 15.70 12.00 CX34-49 CBWMV-60C-100 4261821
XC21-060-230 TXV 58,500 15.70 12.00 CX34-49 CBWMV-60C-120 4261817
XC21-060-230 TXV 58,000 15.50 12.00 CX34-49 G61MPV-60C-090 4261746
XC21-060-230 TXV 57,500 15.50 12.00 CX34-49 G61MPV-60C-091 4261747
XC21-060-230 TXV 58,500 15.50 11.70 CX34-49 G61MPV-60C-110 4261748
XC21-060-230 TXV 58,500 15.50 12.00 CX34-49 G61MPV-60C-111 4261749
XC21-060-230 TXV 58,500 15.70 12.00 CX34-49 SL280UH090V60C 4261744
XC21-060-230 TXV 58,500 15.70 12.00 CX34-49 SL280UH090XV60C 4261823
XC21-060-230 TXV 58,000 15.70 12.00 CX34-49 SL280UH110V60C 4261745
XC21-060-230 TXV 58,000 15.70 12.00 CX34-49 SL280UH110XV60C 4261811
XC21-060-230 TXV 57,500 15.50 12.00 CX34-49 SLP98UH090V60C 4261795
XC21-060-230 TXV 58,000 15.50 11.70 CX34-49 SLP98UH110V60C 4261796
XC21-060-230 TXV 58,500 14.50 12.00 CX34-49 4261739
XC21-060-230 TXV 57,000 15.50 11.70 CX34-50/60C CBWMV-60C-100 4261818
XC21-060-230 TXV 56,500 15.20 11.50 CX34-50/60C G61MPV-60C-090 4261752
XC21-060-230 TXV 57,000 15.20 11.70 CX34-50/60C G61MPV-60C-110 4261753
XC21-060-230 TXV 56,500 15.20 11.50 CX34-50/60C G61MPV-60C-111 4261754
XC21-060-230 TXV 56,500 15.20 11.70 CX34-50/60C SL280UH090V60C 4261750
XC21-060-230 TXV 56,500 15.20 11.70 CX34-50/60C SL280UH090XV60C 4261824
XC21-060-230 TXV 56,500 15.20 11.70 CX34-50/60C SL280UH110V60C 4261751
XC21-060-230 TXV 56,500 15.20 11.70 CX34-50/60C SL280UH110XV60C 4261812
XC21-060-230 TXV 56,000 15.20 11.70 CX34-50/60C SLP98UH090V60C 4261797
XC21-060-230 TXV 56,000 15.20 11.70 CX34-50/60C SLP98UH110V60C 4261798
XC21-060-230 TXV 58,500 16.00 12.20 CX34-60D G61MPV-60D-135 4261756
XC21-060-230 TXV 58,000 16.00 12.50 CX34-60D SL280UH135V60D 4261755
XC21-060-230 TXV 58,000 16.00 12.20 CX34-60D SLP98UH135V60D 4261799
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC21 Specifications

General

SEER Rating	up to 21.00
Sound Rating	as low as 69 dB
Refrigerant	R-410A
Energy Star Certified	Yes
Compressor Type	Two-Stage
Cooling Capacity (BTU/h)	24000-54000
Warranty	10-Year Limited Warranty on compressor
