Lenovo IdeaPad U310/U410 Hardware Maintenance Manual
40
Figure 3. Removal steps of hard disk drive (continued)
U410: Hold the SATA receptacle connector with one hand and pull the hard disk
drive (secured in the metal frame) in the direction shown below to detach the
connectors .
Remove four screws and detach the metal frame from the hard disk drive.
When installing: Make sure that the HDD connector is attached firmly.
Step Screw (quantity) Color Torque
M3.0 × 3.0 mm, flat-head, nylok-coated
(4)
Silver 3.0 kgfcm
