Lenovo ThinkPad OneLink Dock - USB 3.0 Connector with Battery Charging Function; USB 3.0 Connector; Security-Lock Slot; Onelink Cable

3USB3.0connectorwithbatterychargingfunction
TheUSB3.0connectorwithbatterychargingfunctionisusedtodothefollowing:
•ConnectingUSBdevices(USB1.0,USB1.1,USB2.0,andUSB3.0compatible)
•Chargingdevicesevenwhenyournotebookcomputeristurnedoff,insleepmode,orinhibernation
mode;orwhenthedockisdisconnectedfromyournotebookcomputer
4USB3.0connector
TheUSB3.0connectorisusedtoconnectUSBdevices(USB1.0,USB1.1,USB2.0,andUSB3.0
compatible).
5Security-lockslot
Thesecurity-lockslotisusedtosecurethedockwithasecuritycablelock.
Note:Thesecuritycablelockisnotincludedinyouroptionpackage.Ifnecessary,purchaseasecurity
cablelock.
6OneLinkcable
TheOneLinkcableisusedtoconnectthedocktoyournotebookcomputer.
Note:Toavoidanyredamage,ensurethatthenotebookcomputerconnectingtheOneLinkcablemeets
eitherofthefollowingrequirements:
•TheammabilityofthenotebookcomputerenclosureisnotlowerthanClassV-1.
•Thenotebookcomputerenclosureismetallic.
7Cablemanagementstand
ThecablemanagementstandisusedtomanagetheOneLinkcabletooptimizedeskspace.
8Powerconnector
Thepowerconnectorisusedtoconnectthepoweradapter.
Note:Thepowerinputratingofthedockis20Vand3.25A.
9HDMIconnector
TheHDMIconnectorisusedtoconnectanexternalHDMImonitortothedockusinganHDMIcable,
ortoconnectanexternalmonitorwithaVideoGraphicsArray(VGA)connectortothedockusingan
HDMI-to-VGAadapter.
10GigabitEthernetconnector
TheGigabitEthernetconnectorisusedtoconnectthedocktoanetworkusinganEthernetcable.
11USB2.0connectors
ThetwoUSB2.0connectorsareusedtoconnectUSBdevices(USB1.0,USB1.1,andUSB2.0compatible).
Chapter1.Aboutthedock3
