Note:CarefullyhandletheThinkServerRAID700Adapterbyitsedgesandplaceitonaflat,clean,
andstatic-protectivesurfaceafteryouremoveit.
8.Touchthestatic-protectivepackagethatcontainstheTR700Batterytoanyunpaintedsurfaceonthe
outsideoftheserver.Then,taketheTR700Batteryoutofthepackage.
9.HoldtheTR700Batterywiththebatterysideupandtheboard-to-boardconnector1onthebottom
oftheTR700Batteryliningupwiththeconnector2ontheThinkServerRAID700Adapter.Carefully
installtheTR700BatteryontotheThinkServerRAID700Adaptersothatthetwoconnectorsarefirmly
joined.Then,installthethreescrewsthatcomewiththeTR700BatteryoptionkittosecuretheTR
700Batteryinplace.
Notes:
•Centerthescrewdriverwhenyouinstallthescrewsanddonotover-tightenthescrewstoavoid
possibledamagetoanyparts.
•DonottouchtheboardonthebottomoftheTR700Battery.
Figure56.InstallingtheTR700Battery
10.ReinstalltheThinkServerRAID700AdapterwiththeTR700Batterytotherisercardassembly2.See
“InstallingorremovingtheRAIDcard”onpage90.
11.ReconnectcablestotheThinkServerRAID700Adapter.See“Connectingthecables”onpage36.
12.Reinstalltherisercardassembly2.Theprocedureissimilartothatoftherisercardassembly1.See
“Replacingtherisercardassembly1”onpage160
.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage170
.Then,configure
RAIDforyourserver.See“ConfiguringRAID”onpage62.
RemovingtheThinkServerRAID700Battery
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage73.
ThistopicprovidesinstructionsonhowtoremovetheTR700BatteryfromaThinkServerRAID700Adapter
ifyourserverhasaThinkServerRAID700AdapterwithaTR700Batteryinstalled.
