8.Connectthesignalcable1andthepowercable2totherearofthenewopticaldrive.
Figure101.Connectingcablestotherearoftheopticaldrive
9.Slidethenewopticaldrivewiththeretainingbracketandcablesintothedrivebayfromthefrontuntil
itsnapsintoposition.
Figure102.Installingtheopticaldriveforservermodelswith2.5-inchharddiskdrives
10.ConnecttheotherendofthesignalcabletotheSATAconnector0onthesystemboardandconnectthe
otherendofthepowercabletothebackplane.See“Reinstallingtheservercoverandreconnecting
cables”onpage171
.
11.Ifyouareinstructedtoreturntheoldopticaldrive,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage170
.
Installinganexternaltapedrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage73.
144ThinkServerRD340UserGuideandHardwareMaintenanceManual
