•Ifyouarereplacinganopticaldrive,disconnectthesignalcablefromthesystemboardand
disconnectthepowercablefromthebackplane.Presstherearoftheretainingbracket
1inthe
directionasshownandpushtheopticaldrivefromtherearuntilitisprojectedfromthefrontofthe
chassis.Then,holdtheopticaldrivefromthefrontandcompletelyslideitoutofthechassis.
PSU
Mem
CPU
ID
Figure99.Removingtheopticaldriveforservermodelswith2.5-inchharddiskdrives
•Ifyouareinstallinganopticaldrive,removethedummyopticaldrivetray.Thewayofremovingthe
dummyopticaldrivetrayissimilartothewayofremovingtheopticaldrivethatisdescribedabove.
Storethedummyopticaldrivetrayincaseyoulaterremovetheopticaldriveandneedthedummy
opticaldrivetraytocovertheplace.
6.Touchthestatic-protectivepackagethatcontainsthenewopticaldrivetoanyunpaintedsurfaceonthe
outsideoftheserver.Then,takethenewopticaldriveoutofthepackage.
7.Removetheretainingbracketfromtheoldopticaldriveorthedummyopticaldrivetray.Then,installit
onthesideofthenewopticaldrive.
Figure100.Installingtheopticaldriveretainingbracket
Chapter6.Installing,removing,orreplacinghardware143
