8.PositionthePCIExpresssolid-statedrivenearthePCIExpresscardslotontherisercardassembly1.
Then,carefullypressthePCIExpresssolid-statedrivestraightintotheslotuntilitissecurelyseatedand
thebracketalsoissecuredbytherisercardassembly1.
Figure105.InstallingthePCIExpresssolid-statedrive
9.Reinstalltherisercardassembly1.See“Replacingtherisercardassembly1”onpage160.
10.IfyouareinstructedtoreturntheoldPCIExpresssolid-statedrive,followallpackaginginstructionsand
useanypackagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage170
.
ReplacingtheThinkServerRAIDSuperCapacitorModule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage73.
ThistopicprovidesinstructionsonhowtoreplacetheThinkServerRAIDSuperCapacitorModule.Thistopic
appliesonlytoservermodelsthathaveaThinkServerRAIDSuperCapacitorModuleinstalled.
TheThinkServerRAIDSuperCapacitorModuleprotectsthecachememoryontheinstalledThinkServer
RAID710Adapter.YoucanpurchaseaThinkServerRAIDSuperCapacitorModulefromLenovo.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
•UseanydocumentationthatcomeswiththeThinkServerRAIDSuperCapacitorModuleandfollowthose
instructionsinadditiontotheinstructionsinthistopic.
ToreplacetheThinkServerRAIDSuperCapacitorModule,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
Chapter6.Installing,removing,orreplacinghardware147
