Figure7.Frontviewofservermodelswithsix2.5-inchhard-disk-drivebays
1Frontpanel52.5-inchhard-disk-drivearea
2Pull-outinformationcard
6Slimopticaldrive(availableinsomemodels)
3IntelligentDiagnosticsModule
7Leftrackhandle
4Rightrackhandle
1Frontpanel
Fordetailedinformationaboutthecontrols,connectors,andstatusLEDsonthefrontpanel,see“Front
panel”onpage19.
2Pull-outinformationcard
Themachinetype,model,andserialnumberlabeloftheserverisattachedonthepull-outinformationcard.
See“Machinetype,model,andserialnumberlabel”onpage13.
3IntelligentDiagnosticsModule
Formoreinformation,see“IntelligentDiagnosticsModule”onpage22
.
4Rightrackhandle
7Leftrackhandle
Ifyourserverisinstalledinarackcabinet,youcanusetherackhandlestoslidetheserveroutoftherack
cabinet;orusetherackhandlesandscrewstosecuretheserverintherackcabinetsothattheserver
cannotslideout,especiallyinvibration-proneareas.Formoreinformation,refertotheRackInstallation
Instructionsthatcomeswithyourserver.
Chapter3.Productoverview17
