Componentsofservermodelswitheight2.5-inchhard-disk-drivebays
Figure17.Componentsofservermodelswitheight2.5-inchhard-disk-drivebays
1Systemfans
11Risercardassembly2
2CPU2DIMMs(varybymodel)12Oneortwohot-swapredundantpowersupplies
3CPU1DIMMs(varybymodel)
13Hot-swaphard-disk-drivebackplane
4Heatsinks(eachwithamicroprocessor
underneath)
14Rightrackhandle
5Systemboard
152.5-inchhard-disk-drivebays
6Coin-cellbattery
16IntelligentDiagnosticsModule
7PCIExpresscard(availableinsomemodels)
17Pull-outinformationcard
8Coolingshroud
18Leftrackhandle
9Risercardassembly119Frontpanel
10PCIExpresscard(availableinsomemodels)
CRUidentification
CRUsarepartsthatcanbeupgradedorreplacedbythecustomer.IfaCRUisdeterminedtobedefective
duringthewarrantyperiod,areplacementCRUwillbeprovidedtothecustomer.Customersareresponsible
forinstallingtheself-serviceCRUsforthisproduct.Customersalsocaninstalloptional-serviceCRUs,which
mightrequiresometechnicalskillsortools,orrequestthatatechnicianinstalltheoptional-serviceCRU
underthetermsoftheapplicablewarrantyservicetypeforyourcountryorregion.
Non-CRUsmustbereplacedonlybytrainedservicetechnicians.
