ThinkServerRAID710Adapter(alsoknownas9270CV-8iRAIDadapter)
ThefollowingillustrationshowstheconnectorsontheThinkServerRAID710Adapter.
Figure21.ThinkServerRAID710Adapter
1Port1
3ThinkServerRAIDSuperCapacitorModuleconnector
2Port2
1Port1
Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage36.
2Port2
Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage36.
3ThinkServerRAIDSuperCapacitorModuleconnector
UsedtoconnectthecableofaThinkServerRAIDSuperCapacitorModule.See“ReplacingtheThinkServer
RAIDSuperCapacitorModule”onpage147.
Hot-swaphard-disk-drivebackplane
Yourservermightcomewithoneofthefollowinghot-swaphard-disk-drivebayandbackplaneconfigurations:
•Four3.5-inchhard-disk-drivebayswithonebackplane
•Six2.5-inchhard-disk-drivebayswithonebackplane
•Eight2.5-inchhard-disk-drivebayswithonebackplane
Tolocatethebackplane,see“Servercomponents”onpage25.
Backplaneforservermodelswithfour3.5-inchhard-disk-drivebays
Thistopicprovidesinformationtohelpyoulocatetheconnectorsonthebackplaneforservermodels
withfour3.5-inchhard-disk-drivebays.
Chapter3.Productoverview33
