Chapter 1. 1-7
7. Insert the power cord into the monitor, then plug the monitor power cord and the
computer cord into grounded electrical outlets.
Note: A certified power supply cord has to be used with this equipment. The
relevant national installation and or equipment regulations shall be considered.
A certified power supply cord not lighter than ordinary polyvinyl chloride flexible
cord according to IEC 60227 (designation H05VV-F 3G 0.75mm
2
or H05VVH2-F2
3G 0.75mm
2
) shall be used. Alternative a flexible cord be of synthetic rubber
according to IEC 60245 (designation H05RR-F 3G 0.75mm
2
) shall be used.
Note: The type of plug & Socket shown here are for illustration only.
8. Connect the cables with cable clip.
To Next Page
